Technical Specifications
| Specification | Details |
|---|---|
| Product Name | 1756‑M12 |
| Product Type | ControlLogix Memory Module (Nonvolatile Memory Board) |
| Series | Allen‑Bradley ControlLogix |
| Memory Capacity | ~750 kB Nonvolatile Memory |
| Compatibility | Designed for 1756‑L55 ControlLogix systems |
| Backplane Mounting | Internal module on ControlLogix backplane |
| Power Source | Backplane power |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | −40 °C to 85 °C |
| Relative Humidity (Non‑condensing) | 5 % to 95 % |
| Max Operating Altitude | Up to 1000 m above sea level |
| Weight | ~0.09 kg (0.19 lbs) |
| Typical Use | Memory expansion/retention in ControlLogix processors |
FAQ
FAQ
Q1: What is the main purpose of the 1756‑M12 module?
It provides additional nonvolatile memory for compatible ControlLogix controllers to store user programs and data.
Q2: What controllers is this memory module compatible with?
It is designed for use with specific Logix5555 ControlLogix processors such as 1756‑L55 and variants.
Q3: How much memory does this module provide?
Approximately 750 kB of nonvolatile memory.
Q4: How is the module powered?
It is powered through the ControlLogix chassis backplane.
Q5: What are the environmental operating limits?
It operates between 0 °C and 60 °C, with storage from −40 °C to 85 °C.
Q6: What physical size is this memory board?
Typical board dimensions are about 3.8 cm high, 15.2 cm wide, and 14.0 cm deep.
Q7: Is this module still manufactured?
No, the 1756‑M12 has been discontinued by Rockwell Automation; it is available as a legacy/surplus part.
Q8: How heavy is the 1756‑M12 module?
The module weighs roughly 0.09 kg (0.19 lbs).
