Technical Specifications
| Parameter | Specification |
|---|---|
| Product | 1766‑L32BXBA MicroLogix 1400 32‑Point PLC Controller |
| Controller Type | MicroLogix 1400 programmable logic controller with embedded digital and analog I/O |
| Power Supply Input | 24 V DC (Class 2 SELV) |
| Digital Inputs | 20 × 24 V DC (12 fast + 8 standard) |
| Digital Outputs | 12 outputs (6 × relay + 6 × 24 V DC FET; 3 fast + 3 normal DC) |
| Analog Inputs | 4 × voltage analog inputs (12‑bit) |
| Analog Outputs | 2 × voltage analog outputs (12‑bit) |
| Total I/O Points | 32 I/O points (20 I/P + 12 O/P) |
| User Memory | ~20 KB (program + data) |
| Communication Interfaces | 1 × Ethernet 10/100 Mbps; 1 × isolated RS‑232/RS‑485; 1 × non‑isolated RS‑232 serial |
| Communication Protocols | DF1, DH‑485, Modbus RTU/ASCII, DNP3, EtherNet/IP, Modbus TCP/IP |
| Built‑in Display | Backlit LCD for status and monitoring |
| High‑Speed Counters/Pulse Outputs | Up to 6 high‑speed counters; pulse outputs (application dependent) |
| Expansion Support | Supports up to 7 expansion I/O modules (1762 series) |
| Operating Temperature | –20 °C to 60 °C |
| Storage Temperature | –40 °C to 85 °C |
| Humidity (Operating) | 5 % to 95 % non‑condensing |
| Mounting | DIN rail or panel mount |
| Weight | ~0.79 kg (~1.75 lbs) |
| Dimensions (H × W × D) | 90 mm × 180 mm × 87 mm |
| Enclosure Rating | IP20 industrial enclosure |
FAQ
FAQ
Q1. What is the 1766‑L32BXBA used for?
It is a MicroLogix 1400 PLC designed for small to medium industrial automation with both digital and analog I/O.
Q2. What voltage power supply does it require?
The controller operates on 24 V DC input.
Q3. How many digital inputs and outputs does this PLC have?
It has 20 digital inputs and 12 digital outputs (relay + transistor).
Q4. What kind of analog I/O does it support?
It supports 4 analog inputs and 2 analog outputs with 12‑bit resolution.
Q5. What communications interfaces are available?
It includes Ethernet, an isolated RS‑232/RS‑485 combo, and a non‑isolated RS‑232 port.
Q6. What communication protocols are supported?
It supports DF1, DH‑485, Modbus RTU/ASCII, DNP3, EtherNet/IP, and Modbus TCP/IP.
Q7. What are the dimensions and weight of the controller?
Dimensions: 90 mm × 180 mm × 87 mm; weight about 0.79 kg.
Q8. Can its I/O be expanded?
Yes, it supports up to 7 expansion modules from the 1762 series.
