Technical Specifications
| Parameter | Specification |
|---|---|
| Product | 1768-L45 CompactLogix Controller |
| Controller Type | Programmable Logic Controller (PLC) |
| Platform | CompactLogix 1768 Series |
| User Memory | 3 MB standard memory (with optional safety memory on safety versions) |
| Communication Port | 1 × RS-232 serial port |
| Backplane Architecture | 1768 backplane with 1769 I/O expansion support |
| Maximum I/O Modules | Up to 16 × 1769 I/O modules |
| Maximum I/O Banks | Up to 2 banks |
| Maximum 1768 Modules | 2 modules |
| Maximum Motion Modules | 2 modules |
| Backplane Current (5V DC) | ~2.0 A |
| Backplane Current (24V DC) | ~1.3 A |
| Power Consumption | ~33 W |
| Power Dissipation | ~6–9 W (depending on load) |
| Programming Languages | Ladder Diagram, Structured Text, Function Block Diagram, SFC |
| Non-volatile Memory | CompactFlash support |
| Isolation Voltage | RS-232 to system: functional isolation |
| Mounting Type | DIN rail / panel mount |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | –40 °C to 85 °C |
| Humidity | 5% to 95% non-condensing |
| Shock (Operating) | 30 g |
| Vibration (Operating) | 5 g @ 10–500 Hz |
| Weight | ~0.34 kg |
| Dimensions (H × W × D) | 131 mm × 56 mm × 121 mm |
| Application | Mid-range industrial automation control systems |
FAQ
FAQ
Q1. What is the 1768-L45 used for?
It is a CompactLogix PLC used to control industrial machines and automation processes.
Q2. How much memory does it have?
It provides approximately 3 MB of user memory.
Q3. How many I/O modules can it support?
It supports up to 16 × 1769 I/O modules across 2 I/O banks.
Q4. What communication interfaces does it include?
It includes a built-in RS-232 serial communication port.
Q5. Does it support expansion modules?
Yes, it supports both 1768 communication/motion modules and 1769 I/O modules.
Q6. What programming languages are supported?
It supports Ladder Logic, Structured Text, Function Block Diagram, and SFC.
Q7. What is its operating temperature range?
It operates between 0 °C and 60 °C.
Q8. What applications is it typically used in?
It is used in mid-sized industrial automation systems such as machine control and process automation.
