Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Allen-Bradley 1771-IMD/B Digital AC Input Module |
| Product Type | PLC Digital Input Module |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Series | PLC-5 (1771 Series, Revision B) |
| Number of Inputs | 16 Points |
| Input Voltage Range | 10–30 V AC (nominal 24 V AC systems) |
| Input Frequency | 47–63 Hz |
| Input Type | Isolated AC digital input |
| Input Delay | ~1 cycle + filtering (typical 8–20 ms) |
| Backplane Current | 170 mA @ 5 V DC |
| Power Dissipation | Up to 6 W |
| Wiring Arm | 1771-WH |
| Mounting Type | 1771 I/O chassis module |
| Operating Temperature | 0°C to 60°C |
| Dimensions (L × W × H) | 152 mm × 51 mm × 279 mm |
| Weight | 0.5 kg (approx. 1.1 lbs) |
| Lifecycle Status | Discontinued (legacy PLC-5 system) |
FAQ
FAQ
Q1. What is the 1771-IMD/B used for?
It is used to interface 24V AC field devices such as switches, sensors, and relays with PLC-5 systems.
Q2. How many input channels does it provide?
It provides 16 isolated AC input channels.
Q3. What voltage does it support?
It is designed for 10–30 V AC input signals, typically 24 V AC systems.
Q4. What PLC system is it compatible with?
It is compatible with Allen-Bradley PLC-5 systems using the 1771 I/O chassis.
Q5. What is the response time?
It typically responds within 8–20 ms depending on signal conditions.
Q6. What are the physical dimensions?
Approximately 152 mm × 51 mm × 279 mm.
Q7. What is the weight of the module?
About 0.5 kg (1.1 lbs).
Q8. Is the 1771-IMD/B still manufactured?
No, it is discontinued but still widely used in existing industrial installations.
