Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Allen-Bradley 1771-OBD Digital DC Output Module |
| Product Type | PLC Digital Output Module |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Series | PLC-5 (1771 Series) |
| Number of Outputs | 16 Points |
| Output Type | DC Transistor Output (sinking) |
| Output Voltage Range | 10–60 V DC |
| Load Current | Up to 1.0 A per point |
| Output Configuration | Isolated output groups |
| Leakage Current (Off-State) | ≤ 0.5 mA |
| Turn-On Time | < 1 ms (typical) |
| Turn-Off Time | < 1 ms (typical) |
| Backplane Current | 300 mA @ 5 V DC |
| Power Dissipation | Up to 10 W |
| Wiring Arm | 1771-WD |
| Mounting Type | Installed in 1771 I/O chassis |
| Operating Temperature | 0°C to 60°C |
| Dimensions (L × W × H) | 152 mm × 102 mm × 279 mm |
| Weight | 0.7 kg (approx. 1.5 lbs) |
| Lifecycle Status | Discontinued (legacy PLC-5 system) |
FAQ
FAQ
Q1. What is the 1771-OBD used for?
It is used to control DC field devices such as relays, solenoids, and indicators in PLC-5 systems.
Q2. How many output channels does it provide?
It provides 16 DC output points.
Q3. What voltage range does it support?
It supports 10–60 V DC output loads.
Q4. What type of output is it?
It uses transistor-based DC sinking outputs.
Q5. What is the maximum current per output?
Up to 1.0 A per channel.
Q6. What is the switching speed?
Less than 1 millisecond for both ON and OFF transitions.
Q7. What are the physical dimensions?
Approximately 152 mm × 102 mm × 279 mm.
Q8. What is the weight of the module?
Approximately 0.7 kg (about 1.5 lbs).
