Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Allen-Bradley 1771-P6S/B Power Supply Module |
| Product Type | PLC Power Supply Module |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Series | PLC-5 (1771 Series, Revision B) |
| Input Voltage | 194–264 V AC (nominal 220 V AC) |
| Input Frequency | 47–63 Hz |
| Output Voltage | 5 V DC (backplane supply) |
| Output Current | Up to 8 A @ 5 V DC |
| Power Rating | ~56 W typical system load |
| Redundancy Function | Supported (parallel operation with load sharing cable) |
| Sensing Mode | Local / remote sensing selectable |
| Protection | Low-voltage shutdown, overload protection |
| Fuse Rating | 1.5 A, 250 V slow-blow |
| Installation | Single-slot module in 1771 I/O chassis |
| Compatible Chassis | 1771-A1B, A2B, A3B, A3B1, A4B |
| Operating Temperature | 0°C to 60°C |
| Dimensions (L × W × H) | 279 mm × 152 mm × 51 mm |
| Weight | 1.0 kg (approx. 2.2 lbs) |
| Lifecycle Status | Discontinued (legacy PLC-5 system) |
FAQ
FAQ
Q1. What is the 1771-P6S/B used for?
It provides regulated 5 V DC power to a PLC-5 1771 I/O chassis, often in redundant configurations for higher reliability.
Q2. What does the “/B” revision indicate?
It is a hardware revision version with internal improvements while maintaining full functional compatibility.
Q3. What is the output capacity?
It supplies up to 8 A at 5 V DC to the backplane.
Q4. What input voltage does it require?
It operates on 194–264 V AC, typically 220 V AC industrial supply.
Q5. Can two units be used together?
Yes, two modules can operate in parallel for redundancy using a load-sharing cable.
Q6. What happens if voltage drops?
It triggers a shutdown signal to protect PLC memory and system integrity.
Q7. What chassis is it compatible with?
It fits 1771-A series chassis such as A1B, A2B, A3B, A3B1, and A4B.
Q8. What are the physical size and weight?
Approximately 279 × 152 × 51 mm and about 1.0 kg (2.2 lbs).
