Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Embedded Switch Technology |
| Model Number | 1783-ETAP1F |
| Product Type | EtherNet/IP Tap Module |
| Network Ports | 3 Ports Total |
| Copper Ports | 2 x 10/100 Mbps RJ45 Ports |
| Fiber Ports | 1 x 100Base-FX Fiber Port |
| Fiber Connector Type | LC Connector |
| Communication Protocol | EtherNet/IP |
| Supported Topologies | Linear, Star, Device Level Ring (DLR) |
| Transmission Speed | 10/100 Mbps |
| Tap Type | Single Fiber Port EtherNet/IP Tap |
| Power Supply Input | 24V DC (20.4 to 27.6V DC) |
| Current Consumption | Approx. 200 mA @ 24V DC |
| Power Consumption | Approx. 4.8 W |
| Power Dissipation | Approx. 4.8 W |
| Isolation Voltage | 30V Continuous |
| Ethernet Cable Requirement | Category 5e or Higher |
| Mounting Type | DIN Rail or Panel Mount |
| Enclosure Type | Open Style |
| Operating Temperature | -25°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Shock Resistance | 30 G Operating |
| Vibration Resistance | 5 G at 10 to 500 Hz |
| Dimensions | Approx. 131.6 x 35 x 104.9 mm |
| Weight | Approx. 0.76 kg |
| Certifications | UL, CE, CSA, Class I Division 2 |
| Lifecycle Status | Active Mature |
| Typical Applications | Device Level Ring Networks, Industrial Ethernet, PLC Communication |
FAQ
FAQ
Q1: What is the Allen-Bradley 1783-ETAP1F used for?
A1: The 1783-ETAP1F is an EtherNet/IP tap module used to connect industrial devices into Device Level Ring (DLR) and EtherNet/IP industrial Ethernet networks.
Q2: How many ports does the 1783-ETAP1F provide?
A2: The module includes three total ports: two copper RJ45 Ethernet ports and one fiber optic port.
Q3: What communication speed does the 1783-ETAP1F support?
A3: The module supports 10/100 Mbps Ethernet communication for industrial automation networks.
Q4: What power supply is required for the 1783-ETAP1F?
A4: The module operates on a 24V DC power supply with an input range of 20.4 to 27.6V DC.
Q5: Does the 1783-ETAP1F support Device Level Ring (DLR) networks?
A5: Yes. The module is commonly used in DLR network topologies to improve network redundancy and communication reliability in industrial systems.
Q6: Can the 1783-ETAP1F be mounted on a DIN rail?
A6: Yes. The module supports both DIN rail mounting and panel mounting for industrial cabinet installation.
Q7: Is the 1783-ETAP1F suitable for harsh industrial environments?
A7: Yes. The module is designed for industrial automation applications and supports vibration resistance, shock resistance, and Class I Division 2 certifications.
Q8: What are the common applications of the 1783-ETAP1F?
A8: Common applications include industrial Ethernet networking, PLC communication, Device Level Ring architectures, factory automation, and fiber-to-copper network integration.
