Technical Specifications
| Parameter | Details |
|---|---|
| Product Name | Allen-Bradley 1786-RPT |
| Manufacturer | Rockwell Automation (Allen-Bradley) |
| Series | ControlNet Repeater System |
| Product Type | ControlNet Coaxial Panel Mount Repeater |
| Network Type | ControlNet industrial communication network |
| Function | Signal regeneration and extension of ControlNet network segments |
| Communication Medium | RG-6 coaxial cable (75 Ω ControlNet media) |
| Supported Topologies | Star, tree, linear, and mixed ControlNet structures |
| Data Rate | 5 Mbps (ControlNet standard) |
| Input Power | 85–250 VAC or 110–250 VDC |
| Current Consumption | 60 mA (AC) / 25 mA (DC) |
| Backplane / System Function | Supports ControlNet segment extension via repeater architecture |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -40 to 85 °C |
| Humidity | 5 to 95% non-condensing |
| Fault Monitoring | Relay contact output for system diagnostics |
| Mounting Method | Panel mount (industrial enclosure installation) |
| Physical Dimensions (L × W × H) | 17.8 × 13.3 × 10.2 cm |
| Weight | 0.87 kg |
FAQ
FAQ
Q1. What is the main function of the 1786-RPT?
It is used to extend ControlNet networks by regenerating signals and allowing additional network segments.
Q2. What communication network does it support?
It supports the ControlNet industrial communication protocol used in Allen-Bradley PLC systems.
Q3. What type of power supply does it require?
It supports a wide input range of 85–250 VAC or 110–250 VDC.
Q4. What cable type is used with the 1786-RPT?
It uses RG-6 75-ohm coaxial cable designed for ControlNet systems.
Q5. What is the operating temperature range?
It operates between 0 °C and 60 °C in industrial environments.
Q6. Does it support fault detection?
Yes, it includes a fault relay contact for monitoring network status.
Q7. What is the weight of the unit?
It weighs approximately 0.87 kg.
Q8. Is the 1786-RPT still in production?
It is considered a mature/legacy product and may still be available through industrial automation distributors, but it is no longer a new-generation ControlNet component.
