Technical Specifications
| Parameter | Details |
|---|---|
| Product Name | Allen-Bradley 1794-ASB2 |
| Manufacturer | Rockwell Automation (Allen-Bradley) |
| Series | FLEX I/O 1794 |
| Product Type | Remote I/O Adapter |
| Function | Connects FLEX I/O modules to Remote I/O (RIO) network |
| Network Protocol | Remote I/O (RIO) |
| Communication Rate | 57.6 / 115.2 / 230.4 kbps |
| Supported I/O Modules | Up to 2 FLEX I/O modules |
| Backplane Power | 5 VDC via internal FlexBus supply |
| FlexBus Output Current | up to 640 mA @ 5 VDC |
| Power Supply | 24 VDC (nominal) |
| Input Voltage Range | 19.2 to 31.2 VDC |
| Current Consumption | ~330–450 mA @ 24 VDC |
| Power Consumption | ~4.2 W typical |
| Power Dissipation | ~3.4–4.6 W |
| Isolation Voltage | 50 V continuous (basic insulation) |
| Surge Inrush Current | up to 23 A for 2 ms |
| Indicators | LED status (Power, Adapter, I/O, Communication) |
| Communication Cable | Remote I/O twinax cable |
| Mounting Type | DIN rail / panel mount |
| Enclosure Rating | IP20 |
| Operating Temperature | 0 to 55 °C |
| Storage Temperature | -40 to 85 °C |
| Humidity | 5 to 95% non-condensing |
| Physical Dimensions (L × W × H) | 8.7 × 9.4 × 9.2 cm |
| Weight | ~0.20–0.25 kg |
FAQ
FAQ
Q1. What is the main function of the 1794-ASB2?
It is a FLEX I/O Remote I/O adapter used to connect small FLEX I/O systems to a PLC via Remote I/O communication.
Q2. How many I/O modules can it support?
It supports up to 2 FLEX I/O modules per adapter.
Q3. What communication protocol does it use?
It uses the Allen-Bradley Remote I/O (RIO) protocol.
Q4. What is the communication speed range?
It supports 57.6 kbps, 115.2 kbps, and 230.4 kbps selectable baud rates.
Q5. What is the power requirement?
It operates on a 24 VDC supply with an input range of 19.2 to 31.2 VDC.
Q6. What is the purpose of the internal FlexBus power?
It provides 5 VDC backplane power (up to 640 mA) to support connected FLEX I/O modules.
Q7. What are its physical size and weight?
It measures approximately 8.7 × 9.4 × 9.2 cm and weighs about 0.20–0.25 kg.
Q8. What applications is it typically used for?
It is used in legacy industrial automation systems to extend PLC I/O over Remote I/O networks in compact distributed configurations.
