Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | FLEX I/O |
| Model Number | 1794-CE3 |
| Product Type | FLEX I/O Extension Cable |
| Cable Type | Extended-Local Interconnect Cable |
| Cable Length | 0.9 m (3 ft) |
| Connector Type | 15-Pin D-Sub Male-to-Male |
| Connector Style | Shielded Connectors |
| Compatibility | FLEX I/O Adapters, Terminal Bases, FlexLogix Controllers |
| Application Type | Split FLEX I/O System Connection |
| Installation Orientation | Horizontal and Vertical FLEX I/O Expansion |
| Shielding | Yes |
| Communication Support | FLEXBus Backplane Communication |
| Mounting Compatibility | DIN Rail and Panel Systems |
| Enclosure Type | Open Style |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Shock Resistance | 30 G Operating |
| Vibration Resistance | 5 G |
| Certifications | UL, CE, KC, Marine |
| Lifecycle Status | Active Mature |
| Dimensions | Approx. 900 mm Cable Length |
| Weight | Approx. 0.19 – 0.20 kg |
| Typical Applications | FLEX I/O Expansion, Split Rack Installation, Industrial Automation Wiring |
FAQ
FAQ
Q1: What is the Allen-Bradley 1794-CE3 used for?
A1: The 1794-CE3 is a FLEX I/O extension cable used to extend and separate FLEX I/O assemblies in industrial automation systems. It allows FLEX I/O modules to be arranged in multiple rows or different orientations.
Q2: What is the cable length of the 1794-CE3?
A2: The cable length is 0.9 meters (3 feet), making it suitable for medium-distance FLEX I/O expansion connections.
Q3: Which systems are compatible with the 1794-CE3?
A3: The cable is compatible with Allen-Bradley FLEX I/O adapters, terminal bases, and FlexLogix controllers.
Q4: What type of connectors are used on the 1794-CE3?
A4: The cable uses shielded 15-pin D-sub style connectors designed for reliable FLEXBus communication between FLEX I/O components.
Q5: Can the 1794-CE3 be used to create split FLEX I/O layouts?
A5: Yes. The cable is specifically designed to arrange FLEX I/O systems in two rows or separate horizontal and vertical layouts.
Q6: Is the 1794-CE3 suitable for industrial environments?
A6: Yes. The cable supports industrial operating conditions with an operating temperature range of 0°C to 60°C and includes vibration and shock resistance ratings.
Q7: What protection rating does the 1794-CE3 provide?
A7: The cable is rated IP20 and is intended for installation inside industrial control cabinets or protected enclosures.
Q8: Is the 1794-CE3 still available from Rockwell Automation?
A8: Yes. Rockwell Automation currently lists the 1794-CE3 as an Active Mature product within the FLEX I/O product family.
