Technical Specifications
| Parameter | Details |
|---|---|
| Product Name | Allen-Bradley 1794-IB16XOB16P |
| Manufacturer | Rockwell Automation (Allen-Bradley) |
| Series | FLEX I/O 1794 |
| Product Type | Digital Combination I/O Module |
| Function | 16-point 24 VDC sinking inputs + 16-point 24 VDC sourcing protected outputs |
| Total I/O Points | 32 points (16 IN + 16 OUT) |
| Input Type | 24 VDC sinking (NPN) |
| Output Type | 24 VDC sourcing (electronic protected) |
| Input Voltage Range | 10 to 31.2 VDC |
| Output Voltage Range | 10 to 31.2 VDC |
| Input Current | ~2–12 mA per point |
| Output Current | up to 0.5 A per channel |
| Max Output Current (Module) | up to ~8 A total |
| Protection | Electronic short-circuit & overload protection on outputs |
| Backplane Power | 5 VDC via FLEX I/O adapter |
| Backplane Current | ~30–50 mA @ 5 VDC |
| Power Dissipation | ~7 W (typical) |
| Isolation | Field to logic isolation (basic) |
| Response Time | ~1 ms typical (module dependent) |
| Wiring Base | 1794-TB32 / TB32S compatible |
| Communication | Via FLEX I/O adapters (EtherNet/IP, ControlNet, DeviceNet, etc.) |
| Mounting Type | DIN rail |
| Enclosure Rating | IP20 |
| Operating Temperature | 0 to 55 °C |
| Storage Temperature | -40 to 85 °C |
| Humidity | 5 to 95% non-condensing |
| Physical Dimensions (L × W × H) | 6.9 × 9.4 × 9.4 cm |
| Weight | ~0.12–0.20 kg |
FAQ
FAQ
Q1. What is the main function of the 1794-IB16XOB16P?
It is a FLEX I/O combination module that provides both 16 digital inputs and 16 digital outputs in a single unit.
Q2. What type of inputs and outputs does it use?
It uses 24 VDC sinking inputs and 24 VDC sourcing outputs with electronic protection.
Q3. How many total I/O points does it have?
It has 32 total points: 16 inputs and 16 outputs.
Q4. Are the outputs protected?
Yes, each output is electronically protected against overloads and short circuits.
Q5. What is the output current per channel?
Each output channel supports up to 0.5 A, with a total module limit of around 8 A.
Q6. What system does it connect to?
It connects through FLEX I/O adapters such as EtherNet/IP, ControlNet, DeviceNet, or Remote I/O systems.
Q7. What are the physical size and weight?
It measures approximately 6.9 × 9.4 × 9.4 cm and weighs about 0.12–0.20 kg.
Q8. What applications is it typically used for?
It is used in compact industrial automation systems where both input monitoring and output control are required in a single distributed I/O module, such as machine control panels and factory automation lines.
