Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | FLEX I/O-XT |
| Model Number | 1794-IE8XT |
| Product Type | Analog Input Module |
| Module Type | FLEX XT 8-Channel Analog Input Module |
| Number of Inputs | 8 Single-Ended Analog Inputs |
| Input Signal Types | 0…20 mA, 4…20 mA |
| Input Resolution | 16-bit |
| Input Impedance | 249 Ω |
| Input Current Range | 0 to 21 mA |
| Overrange Protection | Yes |
| Isolation Voltage | 50V Continuous, Tested to 850V DC |
| Nominal Supply Voltage | 24V DC |
| Input Voltage Range | 19.2 to 31.2V DC |
| Current Consumption | Approx. 85 mA @ 24V DC |
| FlexBus Current | Approx. 20 mA |
| Conversion Time | Approx. 8 ms |
| Compatible Terminal Bases | 1794-TB3XT, 1794-TB3TXTK |
| Status Indicators | Module and Channel Status LEDs |
| Wiring Type | Single-Ended Analog Wiring |
| Mounting Type | DIN Rail Mount |
| Enclosure Type | Open Style |
| Protection Rating | IP20 |
| XT Environment Rating | Extended Temperature / Harsh Environment |
| Operating Temperature | -20°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Shock Resistance | 30 G Operating |
| Vibration Resistance | 5 G at 10 to 500 Hz |
| Certifications | UL, CE, CSA, ATEX, IECEx, Marine |
| Lifecycle Status | Active Mature |
| Dimensions | Approx. 94 x 94 x 55 mm |
| Weight | Approx. 0.22 kg |
| Typical Applications | Process Automation, Harsh Environment Analog Monitoring, Distributed I/O Systems |
FAQ
FAQ
Q1: What is the Allen-Bradley 1794-IE8XT used for?
A1: The 1794-IE8XT is a FLEX I/O-XT analog input module designed for monitoring current-based analog signals in harsh industrial automation environments.
Q2: How many analog input channels does the 1794-IE8XT provide?
A2: The module provides 8 single-ended analog current input channels for distributed process control applications.
Q3: What signal types are supported by the 1794-IE8XT?
A3: The module supports 0…20 mA and 4…20 mA analog current input signals commonly used in industrial instrumentation.
Q4: What is the resolution of the 1794-IE8XT analog inputs?
A4: The module uses 16-bit analog-to-digital conversion for accurate signal measurement and process monitoring.
Q5: What makes the 1794-IE8XT different from standard FLEX I/O modules?
A5: The XT version is designed for harsh environments and supports extended operating temperatures, hazardous location certifications, and increased environmental durability.
Q6: Which terminal bases are compatible with the 1794-IE8XT?
A6: The module is compatible with 1794-TB3XT and 1794-TB3TXTK FLEX I/O-XT terminal bases.
Q7: Is the 1794-IE8XT suitable for hazardous industrial locations?
A7: Yes. The module includes ATEX, IECEx, and marine certifications for use in demanding industrial and hazardous environments.
Q8: What are the common applications of the 1794-IE8XT?
A8: Common applications include oil and gas systems, chemical processing, marine automation, mining operations, distributed analog monitoring, and industrial process control.
