Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | PowerFlex 750-Series I/O Option Module |
| Model | Allen-Bradley 20-750-2262C-2R |
| Function | Mixed I/O expansion module for drive control and monitoring |
| Compatible Drives | PowerFlex 753 / PowerFlex 755 |
| Supply Voltage | 24 V DC |
| Digital Inputs | 6 (24 V DC, opto-isolated) |
| Analog Inputs | 2 |
| Analog Outputs | 2 |
| Relay Outputs | 2 |
| Total I/O Points | 12 |
| Installation Location | PowerFlex 750 control pod |
| Operating Temperature | -25 to 55 °C |
| Storage Temperature | -40 to 85 °C |
| Humidity | 5–95% non-condensing |
| Altitude | Up to 2000 m |
| Dimensions (H × W × D) | 75 × 140 × 150 mm |
| Weight | 6.8 kg |
FAQ
FAQ
Q1. What is the function of the 20-750-2262C-2R?
It expands the I/O capability of PowerFlex 750-series drives for control and monitoring applications.
Q2. Which drive platforms support this module?
It is designed for PowerFlex 753 and PowerFlex 755 drives.
Q3. How many I/O points does it provide?
It provides a total of 12 points, including analog, digital, and relay outputs.
Q4. What is the input voltage requirement?
It operates on a 24 V DC supply.
Q5. What types of inputs are included?
It includes 6 digital inputs and 2 analog inputs.
Q6. Does it include output capability?
Yes, it has 2 analog outputs and 2 relay outputs.
Q7. Where is it installed in the system?
It is installed inside the PowerFlex 750 drive control pod.
Q8. What are its size and weight?
Its dimensions are 75 × 140 × 150 mm, and it weighs approximately 6.8 kg.
