Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | PowerFlex Communication Adapter |
| Model Number | 20-COMM-E |
| Product Type | EtherNet/IP Communication Adapter |
| Communication Protocol | EtherNet/IP |
| Compatible Drives | PowerFlex 7-Class Drives |
| Supported Products | PowerFlex 70, 700, 700H, 700S, 753, 755 (application dependent) |
| Ethernet Ports | 1 × RJ45 Ethernet Port |
| Network Speed | 10/100 Mbps |
| Interface Type | DPI / Internal Drive Communication |
| Supported Services | I/O Messaging, Explicit Messaging |
| Configuration Method | Drive Parameters, Studio 5000, BOOTP/DHCP |
| LED Indicators | Module Status, Network Status, Link Status |
| Power Supply | Powered by Host Drive |
| Mounting Type | Internal / Drive-mounted |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Protection Rating | IP20 |
| Certifications | UL, CE, CSA |
| Lifecycle Status | Discontinued / Legacy Support |
| Actual Dimensions (H × W × D) | Approx. 110 × 75 × 25 mm |
| Actual Weight | Approx. 0.16 kg |
| Typical Applications | Industrial Ethernet Networking, PLC Integration, Distributed Drive Control |
FAQ
FAQ
Q1: What is the Allen-Bradley 20-COMM-E used for?
A1: The 20-COMM-E is an EtherNet/IP communication adapter used to connect compatible PowerFlex drives to industrial Ethernet networks.
Q2: Which communication protocol does the 20-COMM-E support?
A2: The adapter supports the EtherNet/IP industrial communication protocol.
Q3: Which PowerFlex drives are compatible with the 20-COMM-E?
A3: The adapter is compatible with many Allen-Bradley PowerFlex drives including PowerFlex 70, 700, 700S, 753, and 755 series drives.
Q4: What Ethernet speed does the 20-COMM-E support?
A4: The module supports 10/100 Mbps Ethernet communication.
Q5: How is the 20-COMM-E powered?
A5: The adapter is powered directly by the host drive.
Q6: What are the actual dimensions of the 20-COMM-E?
A6: The approximate dimensions are 110 × 75 × 25 mm (H × W × D).
Q7: What is the actual weight of the 20-COMM-E?
A7: The approximate weight is 0.16 kg.
Q8: What are common applications for the 20-COMM-E?
A8: Common applications include PLC-to-drive communication, industrial Ethernet systems, packaging machinery, conveyor automation, and distributed motor control systems.
