Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | PowerFlex HIM |
| Model Number | 20-HIM-C3 |
| Product Type | Remote Human Interface Module (HIM) |
| Interface Function | Remote Drive Programming and Monitoring |
| Compatible Drives | PowerFlex 70 / 700 / 700H / 700S / 700L |
| Display Type | LCD Display |
| Keypad Type | Full Numeric Keypad |
| Communication Interface | DPI (Drive Peripheral Interface) |
| Mounting Type | Panel / Door Mount |
| Enclosure Rating | NEMA 4X / 12, IP66 |
| Data Functions | Parameter Upload/Download, Diagnostics |
| CopyCat Function | Yes |
| Backlight | Yes |
| Status Indicators | LED Status Indicators |
| Cable Compatibility | 1202-C30 DPI Cable |
| Power Supply | Powered by Host Drive |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Certifications | UL, CE, CSA |
| Lifecycle Status | Legacy / Discontinued |
| Actual Dimensions (H × W × D) | Approx. 180 × 93 × 25 mm |
| Actual Weight | Approx. 0.30 kg |
| Typical Applications | Drive Configuration, Remote Operator Station, Industrial Motor Control |
FAQ
FAQ
Q1: What is the Allen-Bradley 20-HIM-C3 used for?
A1: The 20-HIM-C3 is a remote Human Interface Module (HIM) used for programming, monitoring, and troubleshooting Allen-Bradley PowerFlex drives.
Q2: Which drives are compatible with the 20-HIM-C3?
A2: The module is compatible with PowerFlex 70, 700, 700H, 700S, and other PowerFlex 7-Class drives.
Q3: What type of display does the 20-HIM-C3 include?
A3: The unit includes an LCD display with a full numeric keypad for drive setup and diagnostics.
Q4: What protection rating does the 20-HIM-C3 provide?
A4: The HIM is rated NEMA 4X / 12 and IP66 for industrial environments.
Q5: Can the 20-HIM-C3 upload and download parameters?
A5: Yes. The HIM supports CopyCat parameter upload/download functionality for drive duplication and backup.
Q6: What are the actual dimensions of the 20-HIM-C3?
A6: The approximate dimensions are 180 × 93 × 25 mm (H × W × D).
Q7: What is the actual weight of the 20-HIM-C3?
A7: The approximate weight is 0.30 kg.
Q8: What are common applications for the 20-HIM-C3?
A8: Common applications include remote drive operator stations, AC drive commissioning, parameter configuration, diagnostics, and industrial motor control systems.
