Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Kinetix Cable System |
| Model Number | 2090-CPBM7DF-16AA03 |
| Product Type | Motor Power Cable with Brake Conductors |
| Cable Function | Servo Motor Power and Brake Connection |
| Cable Length | 3 m |
| Compatible Servo Drives | Kinetix 5500 / 5700 Series |
| Compatible Motors | VPL Low-inertia Servo Motors |
| Power Configuration | Single Cable Power with Brake |
| Cable Category | Continuous-Flex Power Cable |
| Connector End 1 | Drive-side Connector |
| Connector End 2 | SpeedTec DIN Circular Connector |
| Power Conductors | 4 Power Conductors + Brake Conductors |
| Wire Gauge | 16 AWG Power Conductors |
| Shielding | Overall Shielded |
| Grounding | Integrated Ground Conductor |
| Cable Jacket | Industrial TPE |
| Cable Color | Orange |
| Flex Rating | Continuous Motion Rated |
| Voltage Rating | 1000V |
| Operating Temperature | -20°C to 90°C |
| Storage Temperature | -40°C to 85°C |
| Minimum Bend Radius | Approx. 10× Cable Diameter |
| Certifications | UL, CE, CSA |
| Lifecycle Status | Active |
| Actual Cable Diameter | Approx. 13.2 mm |
| Actual Weight | Approx. 1.05 kg |
| Typical Applications | Servo Motion Control, Robotics, Packaging Machines, Automated Machinery |
FAQ
FAQ
Q1: What is the Allen-Bradley 2090-CPBM7DF-16AA03 used for?
A1: The 2090-CPBM7DF-16AA03 is a continuous-flex servo motor power cable with integrated brake conductors used to connect Kinetix servo drives to compatible VPL servo motors.
Q2: What is the cable length of the 2090-CPBM7DF-16AA03?
A2: The cable length is 3 meters.
Q3: Which servo systems are compatible with the 2090-CPBM7DF-16AA03?
A3: The cable is designed for Allen-Bradley Kinetix 5500 and Kinetix 5700 servo systems used with compatible VPL low-inertia servo motors.
Q4: What conductor size does the 2090-CPBM7DF-16AA03 use?
A4: The cable uses 16 AWG power conductors with integrated brake wiring.
Q5: Is the 2090-CPBM7DF-16AA03 suitable for continuous-flex applications?
A5: Yes. The cable is continuous-flex rated for robotics, automated machinery, and dynamic motion systems.
Q6: Does the cable include shielding?
A6: Yes. The cable includes overall shielding and an integrated ground conductor for EMI protection and reliable servo performance.
Q7: What are the actual cable dimensions and weight?
A7: The cable diameter is approximately 13.2 mm and the approximate weight is 1.05 kg.
Q8: What are common applications for the 2090-CPBM7DF-16AA03?
A8: Common applications include robotics, servo motion systems, packaging machinery, conveyor automation, and industrial manufacturing equipment.
