Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Kinetix 6000 |
| Model Number | 2094-BM02 |
| Product Type | Axis Module |
| Module Function | Integrated Servo Drive Axis Module |
| Compatible System | Kinetix 6000 Multi-axis Servo Drive System |
| Continuous Output Current | 3.0 A RMS |
| Peak Output Current | 9.0 A RMS |
| Input Voltage | 325V DC Bus |
| Output Voltage | 3-Phase AC Servo Output |
| Compatible Motors | MPL, MPM, MP-Series Servo Motors |
| Feedback Support | High-resolution Motor Feedback |
| Communication Interface | SERCOS Interface |
| Internal Shunt Resistor | No |
| Cooling Method | Air Cooling |
| Mounting Type | Panel Mount |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Certifications | UL, CE, CSA |
| Lifecycle Status | Active |
| Actual Dimensions (H × W × D) | Approx. 279 × 50 × 196 mm |
| Actual Weight | Approx. 1.9 kg |
| Typical Applications | Servo Motion Control, Packaging Machines, Robotics, CNC Systems |
FAQ
FAQ
Q1: What is the Allen-Bradley 2094-BM02 used for?
A1: The 2094-BM02 is a Kinetix 6000 axis servo drive module used to control a single servo motor axis in industrial automation and motion control systems.
Q2: What is the continuous output current of the 2094-BM02?
A2: The module provides 3.0 A RMS continuous output current.
Q3: What is the peak output current of the 2094-BM02?
A3: The peak output current is 9.0 A RMS.
Q4: Which motors are compatible with the 2094-BM02?
A4: The module is compatible with Allen-Bradley MPL, MPM, and MP-Series servo motors.
Q5: Which communication interface does the 2094-BM02 use?
A5: The module uses the SERCOS interface for high-speed servo communication and synchronized motion control.
Q6: What are the actual dimensions of the 2094-BM02?
A6: The approximate dimensions are 279 × 50 × 196 mm (H × W × D).
Q7: What is the actual weight of the 2094-BM02?
A7: The approximate weight is 1.9 kg.
Q8: What are common applications for the 2094-BM02?
A8: Common applications include robotics, packaging equipment, CNC systems, automated machinery, and multi-axis servo motion systems.
