Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Kinetix 6000 |
| Model Number | 2094-BMP5-S |
| Product Type | Integrated Axis Module with Safe Torque-Off |
| Module Function | Servo Drive Power and Axis Control Module |
| Compatible System | Kinetix 6000 Multi-axis Servo Drive System |
| Continuous Output Current | 22 A RMS |
| Peak Output Current | 66 A RMS |
| Input Voltage | 360…480V AC, 3-Phase |
| Input Frequency | 47…63 Hz |
| DC Bus Voltage | 650V DC Nominal |
| Output Voltage | 3-Phase AC Servo Output |
| Compatible Motors | MPL, MPM, MP-Series Servo Motors |
| Communication Interface | SERCOS Interface |
| Safety Feature | Safe Torque-Off (STO) |
| Integrated Power Supply | Yes |
| Internal Shunt Resistor | Yes |
| Cooling Method | Forced Air Cooling |
| Mounting Type | Panel Mount |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Certifications | UL, CE, CSA |
| Lifecycle Status | Active |
| Actual Dimensions (H × W × D) | Approx. 460 × 140 × 196 mm |
| Actual Weight | Approx. 8.6 kg |
| Typical Applications | High-power Servo Motion Control, Robotics, Packaging Systems, CNC Machines |
FAQ
FAQ
Q1: What is the Allen-Bradley 2094-BMP5-S used for?
A1: The 2094-BMP5-S is a Kinetix 6000 integrated servo drive module that combines power supply and axis control functionality for high-performance industrial motion control systems.
Q2: What is the continuous output current of the 2094-BMP5-S?
A2: The module provides 22 A RMS continuous output current.
Q3: What safety feature is included in the 2094-BMP5-S?
A3: The module includes integrated Safe Torque-Off (STO) functionality for machine safety applications.
Q4: Does the 2094-BMP5-S include an integrated power supply?
A4: Yes. The module integrates both servo axis control and power supply functions into a single unit.
Q5: Which communication interface does the 2094-BMP5-S use?
A5: The module uses the SERCOS interface for high-speed synchronized motion communication.
Q6: What are the actual dimensions of the 2094-BMP5-S?
A6: The approximate dimensions are 460 × 140 × 196 mm (H × W × D).
Q7: What is the actual weight of the 2094-BMP5-S?
A7: The approximate weight is 8.6 kg.
Q8: What are common applications for the 2094-BMP5-S?
A8: Common applications include robotics, CNC machinery, packaging systems, material handling equipment, and high-power industrial servo motion systems.
