Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Kinetix 6000M |
| Model Number | 2094-EN02D-M01-S0 |
| Product Type | IAM (Integrated Axis Module) |
| Module Function | Integrated Servo Drive and Power Module |
| Compatible System | Kinetix 6000M Integrated Motion System |
| Input Voltage | 360…480V AC, 3-Phase |
| Input Frequency | 47…63 Hz |
| Continuous Output Current | 9 A RMS |
| Peak Output Current | 27 A RMS |
| DC Bus Voltage | 650V DC Nominal |
| Number of Axes Supported | 1 Axis |
| Communication Interface | SERCOS Interface |
| Safety Feature | Safe Torque-Off (STO) |
| Integrated Power Supply | Yes |
| Compatible Motors | MP-Series and Kinetix Integrated Servo Motors |
| Cooling Method | Forced Air Cooling |
| Mounting Type | Panel Mount |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Certifications | UL, CE, CSA |
| Lifecycle Status | Active |
| Actual Dimensions (H × W × D) | Approx. 460 × 100 × 196 mm |
| Actual Weight | Approx. 6.8 kg |
| Typical Applications | Distributed Servo Motion Control, Packaging Systems, Robotics, Conveyor Automation |
FAQ
FAQ
Q1: What is the Allen-Bradley 2094-EN02D-M01-S0 used for?
A1: The 2094-EN02D-M01-S0 is a Kinetix 6000M integrated axis module used for distributed servo motion control in industrial automation systems.
Q2: What input voltage does the 2094-EN02D-M01-S0 require?
A2: The module operates on 360…480V AC three-phase input power.
Q3: What is the continuous output current of the 2094-EN02D-M01-S0?
A3: The module provides 9 A RMS continuous output current.
Q4: Does the 2094-EN02D-M01-S0 include integrated safety features?
A4: Yes. The module includes Safe Torque-Off (STO) functionality for machine safety applications.
Q5: Which communication interface does the 2094-EN02D-M01-S0 use?
A5: The module uses the SERCOS interface for high-speed synchronized motion communication.
Q6: What are the actual dimensions of the 2094-EN02D-M01-S0?
A6: The approximate dimensions are 460 × 100 × 196 mm (H × W × D).
Q7: What is the actual weight of the 2094-EN02D-M01-S0?
A7: The approximate weight is 6.8 kg.
Q8: What are common applications for the 2094-EN02D-M01-S0?
A8: Common applications include packaging machinery, conveyor systems, robotics, automated assembly equipment, and distributed servo motion control systems.
