Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Single-Axis Servo Drive |
| Model | Allen-Bradley 2097-V34PR3-LM |
| Series | Kinetix 350 |
| Function | EtherNet/IP-based indexing servo drive with integrated line module |
| Input Voltage | 320–528 V AC, 3-phase (nominal 480 V AC) |
| Input Frequency | 48–62 Hz |
| Output Power | 1.0 kW |
| Continuous Output Current | 2.8 A RMS (typical range up to ~5.7 A depending configuration) |
| Control Power | 24 V DC external supply |
| Communication Interface | EtherNet/IP |
| Safety Function | Safe Torque Off (STO) |
| Integrated Feature | Built-in line module (EMI filtering included, LM version) |
| Motor Control Modes | Torque, velocity, position control |
| Protection Functions | Overvoltage, undervoltage, overcurrent, motor overload, thermal protection |
| Mounting Type | Panel mount |
| Operating Temperature | 0 to 50 °C |
| Dimensions (H × W × D) | 238 × 185 × 78.2 mm |
| Weight | ~1.5 kg |
FAQ
FAQ
Q1. What is the 2097-V34PR3-LM used for?
It is a single-axis servo drive used for compact motion control applications such as indexing, positioning, and light automation tasks.
Q2. What does the “LM” suffix indicate?
It indicates an integrated line module, meaning the drive includes built-in EMI/AC line filtering.
Q3. What is the power rating of this drive?
It is rated at approximately 1.0 kW output power.
Q4. What type of power supply does it require?
It operates on 480 V AC three-phase input (320–528 V AC range).
Q5. Does it support industrial Ethernet communication?
Yes, it uses EtherNet/IP for integration with PLC and motion control systems.
Q6. Does it include safety functionality?
Yes, it supports Safe Torque Off (STO) for safe shutdown conditions.
Q7. What are its physical size and weight?
Its dimensions are 238 × 185 × 78.2 mm and it weighs approximately 1.5 kg.
Q8. Is this model still in production?
No, it is part of the Kinetix 350 series, which has been discontinued.
