Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | AC Variable Frequency Drive |
| Model | Allen-Bradley 20AD022A3AYNANC0 |
| Series | PowerFlex 70 |
| Function | Industrial AC motor speed and torque control |
| Input Voltage | 380–480 V AC, 3-phase |
| Input Range | 342–528 V AC |
| Input Frequency | 50/60 Hz |
| Output Voltage | 0–460 V AC, 3-phase |
| Output Current | 22 A |
| Output Power | 11 kW (Normal Duty) / 7.5 kW (Heavy Duty) |
| Horsepower Rating | 15 HP (Normal Duty) / 10 HP (Heavy Duty) |
| Frame Size | D Frame |
| Control Method | Sensorless Vector Control / V/Hz control |
| Communication | EtherNet/IP, DeviceNet, PROFIBUS, Modbus (optional modules) |
| EMC Filter | Integrated EMC filter with common-mode choke |
| Brake Function | Brake IGBT installed (no internal resistor) |
| Control I/O | 6 digital inputs, 2 digital outputs, 2 analog inputs, 1 analog output |
| Protection Functions | Overcurrent, overvoltage, undervoltage, motor overload, ground fault |
| Efficiency | ~97.5% |
| Stop Modes | Coast, ramp, DC brake, fast stop, S-curve |
| Enclosure Rating | IP20 / NEMA Type 1 (panel mount) |
| Operating Temperature | 0 to 50 °C |
| Dimensions (H × W × D) | 350 × 219.9 × 210.7 mm |
| Weight | 9.13 kg |
FAQ
FAQ
Q1. What is the 20AD022A3AYNANC0 used for?
It is a PowerFlex 70 AC drive designed for controlling speed and torque of three-phase AC motors in industrial environments.
Q2. What is its power rating?
It delivers 11 kW (15 HP) under normal duty and 7.5 kW under heavy duty conditions.
Q3. What type of input power does it require?
It operates on a 380–480 V AC three-phase power supply.
Q4. What is the output current capability?
It provides a continuous output current of 22 A.
Q5. Does it include braking capability?
Yes, it includes a built-in brake IGBT, but requires an external brake resistor if braking is needed.
Q6. What communication options are available?
It supports EtherNet/IP and other industrial protocols through optional communication modules.
Q7. What are its physical dimensions?
Its size is approximately 350 × 219.9 × 210.7 mm.
Q8. What is the weight of the unit?
It weighs approximately 9.13 kg.
