Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Model | 20BC170A0ANNACC0 |
| Product Series | PowerFlex 700 |
| Product Type | AC Drive / Variable Frequency Drive |
| Input Voltage | 400 VAC |
| Input Voltage Range | 380–480 VAC |
| Phase | 3-Phase Input / 3-Phase Output |
| Input Frequency | 50 Hz |
| Current Rating | 170 A |
| Power Rating | 90 kW Normal Duty / 75 kW Heavy Duty |
| Frame Size | Frame 6 |
| Enclosure | IP20 / NEMA Type 1 |
| Operator Interface | No HIM, blank plate |
| Control Method | Vector Control |
| Control I/O | 24 VDC I/O |
| Communication | ControlNet via Coax DPI module |
| Feedback | No Feedback |
| Brake IGBT | None |
| Drive-Mounted Brake Resistor | None |
| EMC | Second Environment Filter / Common-Mode Choke |
| Analog Inputs | 2 |
| Analog Outputs | 2 |
| Digital Inputs | 6 |
| Digital Outputs | 3 |
| Maximum Output Frequency | 420 Hz |
| Efficiency | Approx. 97.5% at rated current and nominal line voltage |
| Dimensions (L × W × H) | Approx. 850 × 403.9 × 275.5 mm |
| Weight | Approx. 71.44 kg |
| Country of Origin | USA |
FAQ
FAQ
Q1: What is the 20BC170A0ANNACC0?
It is an Allen-Bradley PowerFlex 700 AC drive for controlling large three-phase industrial motors.
Q2: What is the rated input voltage?
The drive uses a 400 VAC three-phase supply and is rated for the 380–480 VAC range.
Q3: What are the current and motor power ratings?
It is rated at 170 A, with a 90 kW normal-duty rating and 75 kW heavy-duty rating.
Q4: What communication interface does this model use?
This particular configuration uses a ControlNet coaxial DPI communication module. It should not be confused with the 20BC170A3ANNAEC0 version, which uses EtherNet/IP.
Q5: Does it include a HIM keypad?
No. The A0 configuration is supplied with a blank HIM plate rather than an operator keypad/display.
Q6: Does the drive have built-in braking hardware?
No. It has no brake IGBT and no internal drive-mounted brake resistor.
Q7: What enclosure rating does it have?
The drive is rated IP20 / NEMA Type 1 and is intended for installation inside a suitable protected electrical environment.
Q8: Is the 20BC170A0ANNACC0 still manufactured?
No. Rockwell Automation discontinued the PowerFlex 700 20B series on November 30, 2023. Existing units are typically sourced as surplus, replacement stock, or refurbished equipment.
