Technical Specifications
|
Parameter |
Specification |
|---|---|
|
Manufacturer |
Allen-Bradley / Rockwell Automation |
|
Model |
|
|
Product Type |
Adjustable Frequency AC Drive |
|
Product Family |
PowerFlex 700 |
|
Input Voltage |
480 VAC |
|
Input Phase |
3-phase |
|
Input Frequency |
60 Hz |
|
Rated Input Voltage Range |
380–480 VAC |
|
Rated Output Current |
156 A |
|
Normal-Duty Power |
125 HP (approximately 93 kW) |
|
Heavy-Duty Power |
100 HP (approximately 75 kW) |
|
Output Voltage |
0–460 VAC |
|
Control Method |
Vector Control |
|
I/O Configuration |
24 V I/O |
|
Operator Interface |
Blank plate; no HIM keypad included |
|
Feedback |
No encoder feedback |
|
Communication Module |
No internal communication module |
|
EMC Filter |
EMC filter with common-mode choke |
|
Brake IGBT |
Not included |
|
Internal Brake Resistor |
Not included |
|
Enclosure Rating |
IP20 / NEMA 1 / UL Type 1 |
|
Carrier Frequency |
2, 4, 8, or 10 kHz; rating based on 4 kHz |
|
Maximum Output Frequency |
420 Hz |
|
Acceleration/Deceleration |
Two independently programmable times, 0–3600 seconds |
|
Operating Temperature |
0–50°C for the applicable IP20 configuration |
|
Relative Humidity |
5–95%, non-condensing |
|
Shock Rating |
15 G peak for 11 ms |
|
Vibration Rating |
0.152 mm displacement, 1 G peak |
|
Dimensions (H × W × D) |
850.0 × 403.9 × 275.5 mm (33.46 × 15.90 × 10.85 in), including mounting hardware |
|
Net Drive Weight |
71.44 kg (157.5 lb) |
|
Estimated Shipping Weight |
100.9 kg (222.0 lb), including packaging |
|
Mounting Hole Spacing |
825.0 mm high × 300.0 mm wide |
|
Lifecycle Status |
Discontinued; Rockwell Automation lists November 30, 2023, as the discontinuation date for the 20B series |
FAQ
FAQ
Q1: What is the 20BD156A0ANNANC0?
A: It is an Allen-Bradley PowerFlex 700 variable-frequency AC drive for industrial motor speed control.
Q2: What is its rated voltage?
A: It uses a 480 VAC, three-phase supply, with a drive voltage range of 380–480 VAC.
Q3: What are its rated power and output current?
A: It is rated at 125 HP under normal-duty operation and 100 HP under heavy-duty operation, with a rated output current of 156 A.
Q4: Does it include a keypad?
A: No. The catalog configuration is listed with a blank plate and no Human Interface Module (HIM).
Q5: Does it have a built-in braking resistor?
A: No. The catalog listing specifies no internal braking resistor and no brake IGBT.
Q6: What are its dimensions?
A: The dimensions, including mounting hardware, are 850.0 mm high × 403.9 mm wide × 275.5 mm deep.
Q7: What is its weight?
A: The drive weighs approximately 71.44 kg (157.5 lb). The estimated shipping weight with packaging is 100.9 kg (222.0 lb).
Q8: Is this drive still manufactured?
A: No. Rockwell Automation lists the PowerFlex 700 20B series as discontinued. Existing inventory, repair services, or engineering replacement options may still be available.
