Technical Specifications
|
Parameter |
Specification |
|---|---|
|
Model |
|
|
Product Series |
PowerFlex 700 |
|
Product Type |
AC Variable Frequency Drive |
|
Input Voltage |
540 V DC |
|
Input Type |
DC input with precharge |
|
Continuous Output Current |
600 A |
|
1-Minute Overload Current |
660 A |
|
3-Second Overload Current |
900 A |
|
Normal-Duty Power Rating |
350 kW |
|
Heavy-Duty Power Rating |
300 kW |
|
Frame Size |
Frame 8 |
|
PWM Frequency |
2 kHz |
|
Rated Ambient Temperature |
40°C |
|
Control Method |
Vector Control |
|
Motor Control |
Sensorless Vector Control / Vector Control |
|
I/O Type |
24 V I/O |
|
Output |
Three-phase AC output |
|
Feedback |
No feedback |
|
Braking IGBT |
Not included |
|
Dynamic Braking Resistor |
Not included |
|
Communication Module |
Not included |
|
HIM Operator Interface |
Not included |
|
EMC Filter |
Not included |
|
Enclosure Rating |
IP00 |
|
DC Precharge |
Integrated |
|
Cooling Method |
Forced-air cooling |
|
Motor Protection |
Electronic motor overload protection |
|
Acceleration Time |
0–3600 s, programmable |
|
Deceleration Time |
0–3600 s, programmable |
|
Maximum Output Frequency |
Up to 400 Hz, depending on configuration |
|
Dimensions (H × W × D) |
2283.7 × 726.6 × 757.8 mm |
|
Weight |
384 kg |
FAQ
FAQ
Q1: What is the Allen-Bradley 20BP600U0NNNNNC0?
A: The 20BP600U0NNNNNC0 is an Allen-Bradley PowerFlex 700 variable frequency drive designed for industrial motor speed and torque control in DC-bus-powered applications.
Q2: What is the rated output current of this drive?
A: The specified continuous output current is 600 A. The listed overload values are 660 A for one minute and 900 A for three seconds; confirm the applicable overload conditions in the manufacturer’s documentation.
Q3: What are the normal-duty and heavy-duty power ratings?
A: The supplied specifications list 350 kW for normal duty and 300 kW for heavy duty. The applicable rating depends on the operating conditions and drive configuration.
Q4: What input power does the 20BP600U0NNNNNC0 require?
A: It uses a DC bus input with integrated precharge. Verify the required DC bus voltage, polarity, protection, and precharge requirements before connecting the drive.
Q5: What are the dimensions and weight of this model?
A: The supplied reference dimensions are 2283.7 × 726.6 × 757.8 mm (H × W × D), with a weight of 384 kg. Confirm these values against the exact unit and enclosure before installation or shipment.
Q6: Does this model include a communication module or operator interface?
A: The supplied configuration specifies that neither a communication module nor a HIM operator interface is included. Additional hardware may be required for network integration or local operation.
Q7: Does the drive include dynamic braking and motor feedback?
A: The supplied configuration lists no braking IGBT, dynamic braking resistor, or feedback device. Confirm application requirements before selecting external braking equipment or feedback accessories.
Q8: What should be checked before installing or replacing this drive?
A: Verify the DC bus supply, motor current and power, duty rating, cooling requirements, enclosure protection, grounding, control wiring, communication needs, physical clearances, and compatibility with the existing control system.
