Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Allen-Bradley 20F11NC085JA0NNNNN |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Product Series | PowerFlex® 753 |
| Product Type | AC Variable Frequency Drive (VFD) |
| Function | Provides variable speed, torque, and process control for three-phase AC induction motors |
| Application | Pumps, fans, conveyors, compressors, mixers, material handling systems, and general industrial automation |
| Drive Type | AC Drive with Embedded I/O |
| Input Voltage | 380–480 VAC, Three-phase (400 V Class) |
| Nominal Input Voltage | 415 VAC |
| Output Current | 85 A |
| Motor Power Rating | 45 kW (Normal Duty), 37 kW (Heavy Duty) |
| Input Frequency | 50/60 Hz |
| Control Modes | V/Hz Control, Sensorless Vector Control, Closed Loop Vector Control, PID Control |
| Frame Size | Frame 5 |
| Enclosure Rating | IP20 / IP00, NEMA/UL Open Type |
| Cooling Method | Forced Air |
| EMC Filter | Integral EMC Filter (CM Jumper Installed) |
| Dynamic Braking | Built-in Dynamic Braking Transistor |
| Human Interface Module (HIM) | None (Blank, No HIM) |
| Embedded I/O | Standard Embedded I/O |
| Safety | Supports Safe Torque Off (STO) via optional safety module |
| Mounting Type | Panel Mount |
| Operating Temperature | 0°C to +50°C (without derating under specified conditions) |
| Dimensions | Approx. 700 × 325 × 260 mm |
| Weight | Approx. 36 kg |
FAQ
FAQ
Q1: What is the Allen-Bradley 20F11NC085JA0NNNNN used for?
A: The 20F11NC085JA0NNNNN is used to control the speed and torque of three-phase AC motors in industrial applications such as conveyors, pumps, fans, compressors, mixers, and production machinery requiring precise motor control.
Q2: What are the input voltage and power ratings of this drive?
A: The drive operates on a 380–480 VAC three-phase power supply (415 VAC nominal) and is rated for 45 kW in Normal Duty applications or 37 kW in Heavy Duty applications with an 85 A output current.
Q3: Does the 20F11NC085JA0NNNNN include an EMC filter and dynamic braking transistor?
A: Yes. This model includes an integral EMC filter with the CM jumper installed and a built-in dynamic braking transistor, helping reduce electromagnetic interference while supporting applications requiring dynamic braking.
Q4: What enclosure protection does this drive provide?
A: The drive features an IP20/IP00, NEMA/UL Open Type enclosure. It is intended for installation inside a properly protected electrical control cabinet.
Q5: Does this model include a Human Interface Module (HIM)?
A: No. The 20F11NC085JA0NNNNN is supplied with Blank (No HIM). A compatible PowerFlex HIM can be installed separately for local configuration, monitoring, and diagnostics.
Q6: What are the dimensions and weight of the 20F11NC085JA0NNNNN?
A: The drive measures approximately 700 × 325 × 260 mm and weighs approximately 36 kg, making it suitable for panel-mounted industrial installations with adequate cooling clearance.
Q7: What communication and control options are available?
A: The PowerFlex 753 platform supports optional communication modules such as EtherNet/IP, DeviceNet, ControlNet, and other industrial networks. It also supports optional encoder feedback modules, additional I/O, and safety expansion cards to meet a wide range of automation requirements.
Q8: What should be checked before installing the 20F11NC085JA0NNNNN?
A: Before installation, verify the incoming three-phase power supply, motor specifications, wiring, grounding, panel ventilation, braking requirements, and parameter settings. After commissioning, confirm motor rotation, protective functions, communication settings, and overall system performance to ensure reliable operation.
