Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley |
| Manufacturer | Rockwell Automation |
| Product Model | 20F11ND5P0JA0NNNNN |
| Product Type | AC Drive / Variable Frequency Drive |
| Product Series | PowerFlex 753 |
| Drive Family | PowerFlex 750-Series |
| Drive Type | Three-Phase, Air-Cooled AC Drive |
| Input Voltage | 480 VAC |
| Input Voltage Range | 380–480 VAC |
| Input Phase | 3-Phase |
| Input Frequency | 50/60 Hz |
| Continuous Output Current | 5.0 A |
| Normal-Duty Power Rating | 3 HP / 2.2 kW |
| Heavy-Duty Power Rating | 2 HP / 1.5 kW |
| Frame Size | Frame 2 |
| Input Configuration | AC Input with Precharge and DC Terminals |
| Enclosure | IP20/IP00, NEMA/UL Open Type |
| Cooling Method | Forced Air |
| Embedded I/O | Included |
| EMC Filtering | Filtered |
| Common-Mode Jumper | Installed |
| Dynamic Braking | Internal Dynamic Braking Transistor |
| Human Interface Module (HIM) | Blank / No HIM |
| Mounting | Panel / Cabinet Mounting |
| Dimensions (H × W × D) | 424.2 × 134.5 × 212 mm |
| Dimensions (inches) | 16.7 × 5.3 × 8.35 in |
| Weight | Approx. 7.8 kg (17.2 lb) |
| Battery | No |
| Magnet | No |
| Product Lifecycle Status | Active |
FAQ
FAQ
Q1: What is the Allen-Bradley 20F11ND5P0JA0NNNNN?
A: It is a PowerFlex 753 AC drive designed for industrial motor speed control, torque regulation, and automation applications.
Q2: What is the input voltage of this drive?
A: It operates on a 380–480 VAC, three-phase supply, with a nominal voltage class of 480 VAC.
Q3: What are the normal-duty and heavy-duty power ratings?
A: The normal-duty rating is 3 HP (2.2 kW), and the heavy-duty rating is 2 HP (1.5 kW).
Q4: What is the continuous output current?
A: The drive has a continuous output current rating of 5.0 A.
Q5: What are the dimensions and weight of the 20F11ND5P0JA0NNNNN?
A: The approximate dimensions are 424.2 × 134.5 × 212 mm (H × W × D), and the weight is approximately 7.8 kg (17.2 lb).
Q6: Does this drive include embedded I/O?
A: Yes. Embedded I/O is included for control signal connections and integration with industrial automation systems.
Q7: Does the drive include dynamic braking and a HIM?
A: It includes an internal dynamic braking transistor but is supplied without a Human Interface Module (HIM). An external braking resistor may be required depending on the application.
Q8: Is the 20F11ND5P0JA0NNNNN still an active product?
A: Yes. Rockwell Automation lists this model as active. Confirm stock and delivery lead time with the supplier before ordering.
