Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Family | PowerFlex DC |
| Catalog Number | 20P41AD014RA0NNN |
| Drive Type | Regenerative DC Drive |
| Input Voltage | 460 VAC |
| Input Phase | 3 Phase |
| Input Type | 6 Pulse |
| Rated Current | 14 A |
| Motor Power | 7.5 HP / 5.5 kW |
| Motor Operation | Four-Quadrant Operation – Regenerative |
| Field Supply | Single-Phase Regulated |
| Frame Size | Frame A |
| Enclosure | IP20, NEMA/UL Type Open |
| Conformal Coating | Yes |
| HIM | No HIM, blank plate |
| Communication Module | None |
| Dimensions (H × W × D) | 359 × 267 × 287 mm |
| Drive Weight | 8.8 kg |
| Shipping Weight | 11 kg |
FAQ
FAQ
Q1: What is the 20P41AD014RA0NNN?
It is an Allen-Bradley PowerFlex DC regenerative drive designed for controlling DC motors in industrial applications.
Q2: What input voltage does the 20P41AD014RA0NNN use?
It uses 460 VAC three-phase input. Rockwell specifies a 6-pulse input configuration.
Q3: What is the rated current and motor capacity?
The drive is rated at 14 A and supports a normal-duty motor rating of 7.5 HP (5.5 kW).
Q4: Is the 20P41AD014RA0NNN regenerative?
Yes. The 20P41 series provides four-quadrant regenerative operation, allowing controlled motoring and regeneration.
Q5: What frame size is this drive?
It is a Frame A PowerFlex DC drive.
Q6: Does it include a HIM keypad?
No. The 0 HIM option specifies a blank plate/no HIM configuration.
Q7: Does this model include a communication module?
No. The NNN configuration does not include a communication module.
Q8: What are the dimensions and weight?
The approximate dimensions are 359 × 267 × 287 mm (H × W × D). The drive weighs approximately 8.8 kg, with a packaged/shipping weight of about 11 kg.
