Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Model | 20P41AD495RA0NNN |
| Product Type | PowerFlex DC Drive |
| Input Voltage | 480 VAC, 3-phase |
| Rated Output Current | 495 A |
| Motor Power | 300 HP / 224 kW |
| Motor Operation | Four-quadrant operation – regenerative |
| Input Type | 6-pulse |
| Field Supply | Single-phase regulated |
| Frame Size | Frame C |
| Enclosure | IP20, NEMA/UL Type Open |
| Coating | Conformal coating |
| HIM | No HIM, blank plate |
| Communication | No communication module |
| Dimensions (H × W × D) | 521 × 511 × 416 mm |
| Weight | 61 kg |
| Packaged Weight | 83 kg |
FAQ
FAQ
Q1: What is the 20P41AD495RA0NNN?
A: It is an Allen-Bradley PowerFlex DC Drive rated for 480 VAC, 495 A and 300 HP.
Q2: What motor power does this drive support?
A: It is rated for 300 HP (approximately 224 kW).
Q3: Is the 20P41AD495RA0NNN regenerative?
A: Yes. It supports four-quadrant regenerative operation, allowing both motoring and regenerative braking.
Q4: What is the input voltage and phase configuration?
A: The drive uses a 480 VAC, three-phase input with a 6-pulse configuration.
Q5: What type of field supply does it use?
A: It uses a single-phase regulated field supply.
Q6: Does this model include a HIM or communication module?
A: No. The RA0NNN configuration has a blank HIM plate and no communication module.
Q7: What are the dimensions and weight?
A: The Frame C drive measures approximately 521 × 511 × 416 mm (H × W × D) and weighs 61 kg. Packaged weight is approximately 83 kg.
Q8: Is the 20P41AD495RA0NNN still available from Rockwell Automation?
A: Rockwell currently lists it as End of Life, with a planned discontinuation date of April 15, 2027 and no planned Rockwell Automation replacement.
