Technical Specifications
| Item | Specification |
|---|---|
| Product Name | Allen-Bradley 25A-D4P0N104 |
| Product Series | PowerFlex 523 AC Drive |
| Product Type | Variable Frequency Drive (VFD) |
| Application | General-purpose motor speed control (pumps, fans, conveyors, OEM and industrial automation systems) |
| Input Voltage | 380–480 V AC, three-phase |
| Output Voltage | 0–460 V AC, three-phase |
| Output Current | 4.0 A |
| Power Rating | 1.5 kW (2 HP) |
| Frequency Range | 0–590 Hz |
| Control Method | V/Hz control / Sensorless Vector Control |
| Communication | Built-in RS-485 (Modbus RTU) |
| Safety Function | STO (Safe Torque Off) integrated |
| Protection Rating | IP20 (Open Type, Panel Mount) |
| Mounting Type | Panel mount / DIN rail |
| Interface | LCD keypad with basic navigation |
| Frame Size | A |
| Dimensions (L × W × H) | 180 mm × 80 mm × 150 mm |
| Weight | 1.5 kg |
| Cooling Method | Natural convection |
| Operating Temperature | -20°C to +50°C |
| Status | Active |
FAQ
FAQ
Q1. What is the 25A-D4P0N104 used for?
It is used for controlling AC motor speed in industrial automation applications such as pumps, fans, conveyors, and small machinery systems.
Q2. What is the power rating of this drive?
It supports 1.5 kW (2 HP) motor applications.
Q3. What input voltage does it require?
It operates on 380–480 V AC three-phase power supply.
Q4. What is the rated output current?
The drive provides 4.0 A output current.
Q5. What are the exact physical dimensions?
The dimensions are approximately 180 mm × 80 mm × 150 mm.
Q6. What is the weight of the device?
The weight is about 1.5 kg.
Q7. Does it support communication protocols?
Yes, it has built-in RS-485 communication supporting Modbus RTU.
Q8. Does it include safety functions?
Yes, it includes integrated Safe Torque Off (STO) functionality for enhanced safety.
