Technical Specifications
| Item | Specification |
|---|---|
| Product Name | Allen-Bradley 22B-D010N104 |
| Product Series | PowerFlex 40 AC Drive |
| Product Type | Variable Frequency Drive (VFD) |
| Application | Motor speed control for pumps, fans, conveyors, and general industrial automation |
| Input Voltage | 380–480 V AC, three-phase |
| Output Voltage | 0–460 V AC, three-phase |
| Output Current | 10 A – 10.5 A |
| Power Rating | 4.0 kW (5 HP) |
| Frequency Range | 0–400 Hz |
| Control Method | V/Hz control / Sensorless Vector Control |
| Communication | RS-485 (Modbus RTU / DSI) |
| Protection Rating | IP20 (open type, panel mount) |
| Mounting Type | Panel mount |
| Interface | LED display with digital keypad |
| Frame Size | B |
| Dimensions (L × W × H) | 180 mm × 100 mm × 136 mm |
| Weight | 2.2 kg |
| Cooling Method | Natural convection |
| Power Factor | 0.98 |
FAQ
FAQ
Q1. What is the 22B-D010N104 used for?
It is used for controlling the speed of AC motors in industrial applications such as pumps, fans, compressors, and conveyors.
Q2. What is the power rating of this drive?
It supports 4.0 kW (5 HP) motor applications.
Q3. What input voltage does it require?
It operates on 380–480 V AC three-phase input.
Q4. What is the rated output current?
The drive provides approximately 10–10.5 A output current.
Q5. What are the exact physical dimensions?
The dimensions are about 180 mm × 100 mm × 136 mm.
Q6. What is the weight of the device?
The weight is approximately 2.2 kg.
Q7. Does it support communication protocols?
Yes, it supports RS-485 communication using Modbus RTU / DSI.
Q8. Is this model still available?
No, it has been officially discontinued as of June 30, 2025.
