Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | PowerFlex 525 |
| Model Number | 25B-D2P3N114 |
| Product Type | AC Variable Frequency Drive (VFD) |
| Drive Type | Adjustable Frequency AC Drive |
| Input Voltage | 380…480V AC |
| Nominal Voltage Class | 480V AC |
| Input Phase | 3-Phase |
| Input Frequency | 50/60 Hz |
| Output Voltage | 0…460V AC |
| Output Frequency Range | 0…500 Hz |
| Rated Output Current | 2.3 A |
| Output Power | 0.75 kW / 1 HP |
| Normal Duty Rating | 0.75 kW / 1 HP |
| Heavy Duty Rating | 0.75 kW / 1 HP |
| Frame Size | Frame A |
| Enclosure Rating | IP20 / NEMA Open Type |
| EMC Filter | Integral EMC Filter Included |
| Brake IGBT | Included |
| Communication Ports | Embedded EtherNet/IP, RS-485, USB |
| Supported Protocols | EtherNet/IP, Modbus RTU |
| Digital Inputs | 7 |
| Digital Outputs | 4 |
| Analog Inputs | 2 |
| Analog Outputs | 1 |
| Control Methods | V/Hz, Sensorless Vector, Closed Loop Vector, PM Motor Control |
| Safety Features | Safe Torque Off (STO), SIL2 / PLd Cat 3 |
| User Interface | Integral Keypad with Potentiometer and LED Display |
| Mounting Type | Panel Mount |
| Cooling Method | Natural Air Cooling |
| Power Factor | 0.98 |
| Operating Temperature | -20°C to +50°C |
| Extended Temperature Capability | Up to +70°C with derating |
| Certifications | UL, CE, cUL, KC, RCM, Marine |
| Lifecycle Status | Active |
| Actual Dimensions (H × W × D) | Approx. 152 × 72 × 172 mm |
| Actual Weight | Approx. 1.5–2.7 kg |
| Typical Applications | Conveyors, Fans, Pumps, Mixers, Packaging Machines, OEM Equipment |
FAQ
FAQ
Q1: What is the Allen-Bradley 25B-D2P3N114 used for?
A1: The 25B-D2P3N114 is a PowerFlex 525 AC drive used for variable-speed control of industrial AC motors with integrated networking and safety functions.
Q2: What motor size can the 25B-D2P3N114 control?
A2: The drive supports motors up to 0.75 kW (1 HP) with a rated output current of 2.3 A.
Q3: Does the 25B-D2P3N114 include an EMC filter?
A3: Yes. Unlike the 25B-D2P3N104 version, the 25B-D2P3N114 includes an integral EMC filter.
Q4: Does the drive include EtherNet/IP communication?
A4: Yes. Embedded EtherNet/IP communication is included, along with RS-485 and USB interfaces.
Q5: Does the 25B-D2P3N114 include Safe Torque Off (STO)?
A5: Yes. Integrated Safe Torque Off functionality is included and certified to SIL2 / PLd Category 3 safety standards.
Q6: Does the 25B-D2P3N114 include a brake transistor?
A6: Yes. The drive includes an internal brake IGBT/chopper for dynamic braking applications.
Q7: What are the actual dimensions and weight of the 25B-D2P3N114?
A7: The approximate dimensions are 152 × 72 × 172 mm, and the actual weight is approximately 1.5–2.7 kg depending on source and packaging method.
Q8: What are common applications for the 25B-D2P3N114?
A8: Common applications include conveyors, pumps, fans, mixers, packaging systems, and OEM machinery requiring compact networked motor-speed control.
