Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Product Series | PanelView 600 |
| Model Number | 2711-B6C9 |
| Product Type | Operator Interface Terminal / HMI |
| Display Size | 6 in. |
| Display Type | Color STN LCD |
| Display Resolution | 320 × 240 Pixels |
| Display Colors | 256 Colors |
| Operator Interface | Keypad and Touchscreen |
| Function Keys | 10 Programmable Function Keys |
| Touchscreen Type | Analog Resistive |
| Communication Port | DH+ and RS-232 Printer/Download Port |
| Communication Speed | 57.6K / 115.2K / 230.4K baud |
| Power Supply | 85–264V AC |
| Input Frequency | 47–63 Hz |
| Runtime Memory | 240 KB |
| Nonvolatile Memory | 240 KB |
| Backlight Type | Replaceable Backlight |
| Backlight Life | Approx. 50,000 Hours |
| Mounting Type | Panel Mount |
| Enclosure Rating | NEMA Type 12/13, 4X Indoor Rated |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 70°C |
| Dimensions (H × W × D) | 290 × 244 × 112 mm |
| Weight | Approx. 2.3 kg / 5.07 lb |
| Product Status | Discontinued / Obsolete |
FAQ
FAQ
Q1: What is the Allen-Bradley 2711-B6C9 used for?
A1: The 2711-B6C9 is a PanelView 600 operator terminal used for industrial automation applications, providing machine monitoring, process visualization, and operator control.
Q2: What type of display does the 2711-B6C9 have?
A2: This model features a 6-inch color STN LCD display with a resolution of 320 × 240 pixels and support for 256 colors.
Q3: Does the 2711-B6C9 support both keypad and touchscreen operation?
A3: Yes. The terminal combines an analog resistive touchscreen with ten programmable function keys for flexible machine interaction.
Q4: Which communication protocols are supported by this terminal?
A4: The unit supports DH+ communication and includes an RS-232 printer/download port for configuration and data transfer.
Q5: What power input does the 2711-B6C9 require?
A5: The terminal operates on an AC power supply ranging from 85V to 264V AC at 47–63 Hz.
Q6: Is the 2711-B6C9 still manufactured?
A6: No. The model has been discontinued by Allen-Bradley, but refurbished and surplus units are still commonly available.
Q7: What enclosure protection rating does this HMI provide?
A7: The terminal is rated NEMA Type 12/13 and 4X for indoor environments, offering protection against dust, oil, and light water exposure.
Q8: What are the dimensions and weight of the 2711-B6C9?
A8: The unit measures approximately 290 × 244 × 112 mm and weighs about 2.3 kg (5.07 lb).
