Technical Specifications
| Item | Specification |
|---|---|
| Product Name | Allen-Bradley 2711P-B15C4A9 |
| Product Series | PanelView Plus 1500 |
| Product Type | Operator Interface Terminal (HMI) |
| Application | Industrial automation visualization and control (PLC-based systems) |
| Display Type | Color TFT LCD |
| Display Size | 15 in |
| Resolution | 1024 × 768 pixels (XGA) |
| Input Type | Keypad + Touchscreen |
| Touch Technology | 8-wire analog resistive touch |
| Input Voltage | 18–32 V DC (24 V DC nominal) |
| Communication Ports | Ethernet (10/100 Mbps), RS-232, USB host ports |
| Memory | 512 MB RAM / 512 MB nonvolatile memory |
| Operating System | Windows CE-based system |
| Software | FactoryTalk View Machine Edition |
| Protection Rating | IP54 / IP65 (front panel installed), NEMA 4X |
| Backlight | CCFL (field replaceable) |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -25°C to 70°C |
| Dimensions (L × W × H) | 330 mm × 416 mm × 65 mm |
| Weight | 4.5 kg |
FAQ
FAQ
Q1. What is the 2711P-B15C4A9 used for?
It is a PanelView Plus 1500 HMI used for industrial machine monitoring and control in PLC systems.
Q2. What size is the display?
It has a 15-inch color TFT LCD display with 1024 × 768 resolution.
Q3. Does it support touchscreen operation?
Yes, it uses a resistive touchscreen combined with a physical keypad.
Q4. What communication interfaces does it support?
It supports Ethernet, RS-232, and USB host ports for connectivity and programming.
Q5. What are its physical dimensions?
The front dimensions are approximately 330 mm × 416 mm × 65 mm.
Q6. What is the weight of the device?
The approximate weight is 4.5 kg.
Q7. What software is used for programming?
It is configured using FactoryTalk View Machine Edition software.
Q8. What is the protection rating?
It has NEMA 4X and IP65 front-panel protection when properly installed.
