Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Product Series | PanelView Plus 600 |
| Model Number | 2711P-K6C20A |
| Product Type | Operator Interface Terminal / HMI |
| Display Size | 5.7 in. |
| Display Type | Color Active Matrix TFT LCD |
| Display Resolution | 320 × 240 Pixels |
| Display Colors | 18-Bit Color Graphics |
| Display Area | 115 × 86 mm |
| Operator Interface | Keypad |
| Keypad Type | Membrane Keypad |
| Function Keys | 10 Programmable Function Keys |
| Communication Ports | EtherNet/IP, RS-232, USB |
| Ethernet Speed | 10/100 Mbps |
| USB Ports | 1 USB Host Port, 1 USB Device Port |
| Power Supply | 100–240V AC |
| Input Frequency | 50/60 Hz |
| Power Consumption | Approx. 60 W |
| Internal Memory | 64 MB RAM / 64 MB Flash |
| External Storage | CompactFlash Card Supported |
| Operating System | Windows CE |
| Backlight Type | Replaceable CCFL Backlight |
| Backlight Life | Approx. 50,000 Hours |
| Mounting Type | Panel Mount |
| Enclosure Rating | NEMA Type 12/13, 4X Indoor / IP54, IP65 |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -25°C to 70°C |
| Dimensions (H × W × D) | 212 × 290 × 112 mm |
| Weight | Approx. 2.3 kg / 5.1 lb |
| Software Compatibility | FactoryTalk View Machine Edition |
| Product Status | Discontinued / Obsolete |
FAQ
FAQ
Q1: What is the Allen-Bradley 2711P-K6C20A used for?
A1: The 2711P-K6C20A is a PanelView Plus 600 HMI terminal designed for industrial automation applications, including machine monitoring, operator control, and process visualization.
Q2: What type of operator interface does the 2711P-K6C20A use?
A2: This model uses a keypad-only interface with programmable membrane function keys for industrial machine operation.
Q3: What display specifications does the terminal provide?
A3: The terminal features a 5.7-inch color TFT LCD display with a resolution of 320 × 240 pixels and 18-bit color graphics.
Q4: Which communication interfaces are available on the 2711P-K6C20A?
A4: The unit supports EtherNet/IP communication and includes Ethernet, RS-232, and USB ports for industrial connectivity and peripheral integration.
Q5: What power input does the 2711P-K6C20A require?
A5: The terminal operates on 100–240V AC power with a 50/60 Hz input frequency range.
Q6: What software is used to configure this HMI terminal?
A6: The 2711P-K6C20A is configured using FactoryTalk View Machine Edition software from Rockwell Automation.
Q7: Is the 2711P-K6C20A still manufactured by Allen-Bradley?
A7: No. This model has been discontinued, although refurbished and surplus units are still available through industrial automation suppliers.
Q8: What are the dimensions and weight of the 2711P-K6C20A?
A8: The terminal measures approximately 212 × 290 × 112 mm and weighs about 2.3 kg (5.1 lb).
