Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley Compact GuardLogix 5380 |
| Model Number | 5069-L320ERS2 |
| Controller Type | Safety CompactLogix Controller |
| Safety Rating | SIL 2 / PLd capable |
| Standard Memory | 2 MB |
| Safety Memory | 1 MB |
| Total Memory | 3 MB (standard + safety) |
| Processor | High-performance industrial processor |
| Communication Ports | 2 × Ethernet (1 Gb), 1 × USB |
| EtherNet/IP Nodes | Up to 40 nodes |
| Integrated Motion Control | Not included |
| I/O Capacity | Up to 16 Compact 5000 I/O modules |
| Network Topologies | Linear, Star, Device Level Ring (DLR) |
| Programming Software | Studio 5000 Logix Designer |
| Supported Languages | Ladder Diagram, Structured Text, Function Block, SFC |
| Power Supply | 18–32V DC |
| Power Consumption | System dependent (~1 A @ 24V DC typical) |
| Dimensions | 98.1 × 143.97 × 136.81 mm (W × H × D) |
| Weight | Approx. 0.9–1.2 kg |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Product Status | Active |
FAQ
FAQ
Q1. What is the 5069-L320ERS2 used for?
It is a Compact GuardLogix safety controller used for machine automation requiring integrated safety control.
Q2. What safety level does this controller support?
It supports SIL 2 and PLd safety standards for industrial safety applications.
Q3. How much memory does it provide?
It includes 2 MB standard memory and 1 MB safety memory.
Q4. Does it support motion control?
No, this model does not include integrated motion capability (unlike ERM variants).
Q5. How many I/O modules can it handle?
It supports up to 16 Compact 5000 I/O modules.
Q6. What communication interfaces are available?
It provides dual Gigabit Ethernet ports and one USB port for programming and networking.
Q7. What software is used for programming?
It is programmed using Studio 5000 Logix Designer.
Q8. What type of applications is it best suited for?
It is used in safety-critical systems such as packaging machines, automated production lines, and material handling systems requiring integrated safety control.
