Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley CompactLogix 5380 |
| Model Number | 5069-L330ERM |
| Controller Type | Motion-enabled CompactLogix Ethernet Controller |
| Application Memory | 3 MB |
| Processor | High-performance quad-core processor |
| Communication Ports | 2 × Ethernet (10/100/1000 Mbps), 1 × USB 2.0 |
| EtherNet/IP Nodes | Up to 50–60 nodes |
| Integrated Motion Control | Up to 16 axes (CIP Motion) |
| I/O Capacity | Up to 31 Compact 5000 I/O modules |
| Network Topologies | Linear, Star, Device Level Ring (DLR) |
| Programming Software | Studio 5000 Logix Designer |
| Supported Languages | Ladder Diagram, Structured Text, Function Block, SFC |
| Power Supply | 18–32V DC |
| Power Consumption | Max. approx. 8.5 W |
| Non-volatile Memory | SD card support (1784-SD series) |
| Mounting Type | DIN rail |
| Dimensions | 98.1 × 143.97 × 136.81 mm (W × H × D) |
| Weight | Approx. 0.17–3.0 kg (varies by packaging/source) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| System Compatibility | Compact 5000 I/O platform |
FAQ
FAQ
Q1. What is the 5069-L330ERM used for?
It is a high-performance CompactLogix controller designed for automation systems requiring motion control and large I/O capacity.
Q2. How much memory does it provide?
It includes 3 MB of user application memory.
Q3. How many I/O modules can it support?
It supports up to 31 Compact 5000 I/O modules.
Q4. Does it support motion control?
Yes, it supports integrated motion with up to 16 axes over EtherNet/IP.
Q5. What communication interfaces are available?
It includes dual Gigabit Ethernet ports and one USB port.
Q6. What network topologies are supported?
It supports Device Level Ring (DLR), star, and linear Ethernet topologies.
Q7. What is the power requirement?
It operates on 18–32V DC with a maximum power dissipation of about 8.5 W.
Q8. What type of applications is it best suited for?
It is ideal for medium to large automation systems that require high-speed communication, motion control, and scalable I/O expansion.
