Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley Compact 5000 I/O System |
| Model Number | 5069-AENTRXT |
| Product Type | EtherNet/IP Adapter (Extended Temperature / Hardened Variant) |
| Communication Protocol | EtherNet/IP |
| Ethernet Ports | 2 × RJ45 (Integrated switch) |
| Supported Topologies | Linear, Star, Device Level Ring (DLR) |
| I/O Capacity | Up to 31 Compact 5000 I/O modules per adapter |
| Input Voltage | 18–32V DC |
| Power Consumption | Approx. 3.5–8.5 W (system dependent) |
| Data Rate | 10/100/1000 Mbps (1 Gb capable switching) |
| Isolation Voltage | 250–300V continuous (system dependent) |
| Operating Temperature | -40°C to 70°C (extended temperature range) |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Protection Rating | Industrial IP20 (open-style enclosure) |
| Dimensions | 138 × 56 × 105 mm |
| Weight | Approx. 0.17 kg (170 g) |
| Mounting Type | DIN rail |
| Diagnostics | Advanced module-level diagnostics with status indicators |
| Software Compatibility | Studio 5000 Logix Designer |
| System Compatibility | CompactLogix 5380 / 5480 controllers |
FAQ
FAQ
Q1. What is the 5069-AENTRXT used for?
It is a Compact 5000 EtherNet/IP adapter used to connect distributed I/O modules to a CompactLogix control system, especially in harsher temperature environments.
Q2. What is different from the standard 5069-AENTR?
The “XT” version is designed for extended temperature ranges and more demanding industrial environments.
Q3. How many I/O modules can it support?
It supports up to 31 Compact 5000 I/O modules per adapter.
Q4. Does it support Device Level Ring (DLR)?
Yes, it supports DLR for network redundancy and higher availability.
Q5. What communication speed does it support?
It supports 10/100/1000 Mbps Ethernet with integrated switch capability.
Q6. What is its operating temperature range?
It operates from -40°C to 70°C, suitable for harsh environments.
Q7. What software is used for configuration?
It is configured using Studio 5000 Logix Designer.
Q8. What is the weight of the module?
Approximately 0.17 kg (170 g).
