Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Model | 5094-RTB32C |
| Product Family | FLEX 5000 I/O |
| Product Type | Removable Terminal Block |
| Terminal Type | Screw |
| I/O Capacity | 32 output terminals |
| Maximum I/O Rating | 2 A @ 32 VDC |
| Sensor Actuator Power (SA) | 10 A @ 18–32 VDC |
| Isolation Voltage | 250 V continuous, basic insulation |
| Wire Type | Copper |
| Wire Size | 0.34–2.5 mm² (22–14 AWG) |
| Terminal Screw Torque | 0.4 N·m (3.5 lb·in) |
| Dimensions (H × W × D) | 53.0 × 94.0 × 76.0 mm |
| Weight | Approx. 202 g |
FAQ
FAQ
Q1: What is the 5094-RTB32C?
A: It is an Allen-Bradley FLEX 5000 32-point removable screw terminal block used for field wiring connections.
Q2: How many terminals does the 5094-RTB32C have?
A: It provides 32 output terminals, numbered 0 through 31.
Q3: What is the maximum I/O rating?
A: The maximum input/output rating is 2 A at 32 VDC.
Q4: What is the Sensor Actuator power rating?
A: The SA power rating is 10 A at 18–32 VDC.
Q5: What wire size is supported?
A: It accepts 0.34–2.5 mm² (22–14 AWG) solid or stranded copper wire rated for at least 105°C.
Q6: What is the terminal screw torque?
A: The specified screw-terminal torque is 0.4 N·m (3.5 lb·in).
Q7: What are the dimensions and weight?
A: The approximate dimensions are 53.0 × 94.0 × 76.0 mm (H × W × D), and the weight is approximately 202 g.
Q8: Is the 5094-RTB32C still an active product?
A: Yes. Rockwell Automation currently lists the 5094-RTB32C as Active. The listed country of origin is Singapore.
