Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley Motor Control Components |
| Model Number | 815-BOV169 |
| Product Type | Thermal Overload Relay (Manual Reset) |
| Function | Protects motors from overcurrent/overload conditions |
| Relay Type | Solid-state / thermal overload relay |
| Rated Voltage | Up to 600 VAC |
| Rated Current | Up to 25 A AC |
| Reset Method | Manual reset |
| Contact Type | Screw terminals (6 terminals) |
| Mounting Type | Panel / base-mounted (2 mounting holes) |
| Operation Principle | Heat generated by current triggers trip mechanism |
| Special Features | Indirectly heated, multi-relay protection design |
| Dimensions | 95.25 × 57.15 × 100 mm (approx. 3.75″ × 2.25″ × 3.94″) |
| Weight | Approx. 0.29–0.39 kg (0.65–0.75 lb) |
| Operating Temperature | Typical industrial environment (0°C to 50°C) |
| Storage Temperature | -40°C to 85°C |
| Product Status | Discontinued (legacy part) |
FAQ
FAQ
Q1. What is the 815-BOV169 used for?
It is a thermal overload relay designed to protect electric motors from overheating due to overcurrent.
Q2. How does this relay work?
It trips when internal heat—generated by excessive current—reaches a threshold, disconnecting the circuit.
Q3. What is the maximum voltage rating?
It supports up to 600 VAC for motor control applications.
Q4. What type of reset does it use?
It features a manual reset mechanism after a trip condition.
Q5. What is the current rating?
It supports up to approximately 25 A AC.
Q6. Is this product still manufactured?
No, it has been discontinued and is typically available only as surplus or refurbished inventory.
Q7. Where is it typically installed?
It is installed in motor starters or control panels to provide overload protection.
Q8. What is the weight of the relay?
Approximately 0.29 to 0.39 kg (0.65–0.75 lb) depending on revision.
