Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Allen-Bradley PowerFlex 750-Series |
| Model Number | SK-R9-PINT2-CF7A |
| Product Type | Power Interface Board Kit |
| System Compatibility | PowerFlex 750-Series AC Drive (Frame 7) |
| Function | Interfaces AC input, rectifier stage, DC bus, and inverter section |
| Voltage Rating | 400 V AC |
| Power Rating | Approx. 160 kW (Frame 7 configuration) |
| Drive Frame Size | Frame 7 |
| Application | Main power conversion and DC link interface in VFD system |
| Installation Type | Internal drive-mounted replacement kit |
| Electrical Role | Power structure interface (non-programmable hardware) |
| Cooling Method | Cabinet air-cooled via drive heatsink system |
| Environmental Use | Industrial enclosed drive cabinet only |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | Approx. 305 × 203 × 51 mm |
| Weight | Approx. 0.2–0.5 kg |
FAQ
FAQ
Q1. What is the SK-R9-PINT2-CF7A used for?
It is a power interface kit used in PowerFlex 750 Frame 7 drives to manage power flow between AC input, DC bus, and inverter stages.
Q2. What drives is it compatible with?
It is designed specifically for Allen-Bradley PowerFlex 750-Series Frame 7 drives.
Q3. What is its main function?
It provides the internal electrical interface for power conversion within the drive system.
Q4. Is it a standalone device?
No, it is an internal replacement component used only inside compatible drives.
Q5. What power level does it support?
It is typically used in 400 V systems rated around 160 kW.
Q6. Does it require programming?
No, it is a hardware component with no software configuration.
Q7. What happens if it fails?
The drive may lose power conversion capability and fail to operate.
Q8. What is the weight of the module?
Approximately 0.2–0.5 kg, depending on revision and packaging.
