Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Modbus Master/Slave Communication Module |
| Model Number | MVI56E-MCMR |
| Manufacturer | ProSoft Technology (Rockwell Automation Encompass Partner) |
| Platform | Allen-Bradley ControlLogix (1756 chassis) |
| Module Type | Enhanced Modbus Master/Slave communication module |
| Communication Protocol | Modbus RTU / ASCII (Master & Slave) |
| Serial Ports | 1 × isolated serial port (RS-232 / RS-485 configurable) |
| Backplane Current | ~800 mA @ 5 V DC |
| Slot Requirement | Single-slot ControlLogix module |
| Data Transfer | Through ControlLogix processor via backplane memory mapping |
| Configuration | via Studio 5000 / ProSoft Configuration Builder |
| Memory | On-board non-volatile memory for configuration & buffers |
| Dimensions | Approx. 145 × 35 × 140 mm |
| Weight | Approx. 0.3 kg |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Function | Industrial Modbus communication gateway module |
| System Role | Protocol interface between ControlLogix and Modbus devices |
FAQ
FAQ
Q1: What is the MVI56E-MCMR module?
It is a ProSoft ControlLogix communication module that enables Modbus RTU Master/Slave functionality for Allen-Bradley PLC systems.
Q2: Which PLC platform does it support?
It is designed for the Allen-Bradley ControlLogix platform using the 1756 chassis.
Q3: What communication protocols does it support?
It supports Modbus RTU and Modbus ASCII in both Master and Slave modes.
Q4: How many serial ports does it have?
It includes one isolated serial communication port configurable as RS-232 or RS-485.
Q5: What is its main application?
It is used for integrating Modbus devices such as energy meters, VFDs, sensors, and remote I/O into ControlLogix systems.
Q6: How does it communicate with the PLC?
It exchanges data through the ControlLogix backplane using mapped memory and tags.
Q7: What software is used for configuration?
It is configured using Studio 5000 and ProSoft Configuration Builder (PCB).
Q8: Why is this module widely used in industry?
Because it allows seamless integration of widely used Modbus devices into Rockwell ControlLogix systems without custom programming.
