Technical Specifications
| Item | Specification |
|---|---|
| Model | 18622-010-01 |
| Type | Accelerometer / Seismic Vibration Sensor |
| Measurement Principle | Piezoelectric acceleration sensing |
| Measurement Range | 0 to 50 g (typical) |
| Frequency Response | 10 Hz to 5 kHz (±10%) |
| Sensitivity | 100 mV/g (nominal) |
| Transverse Sensitivity | < 5% of primary sensitivity |
| Output Type | IEPE (Integrated Electronics Piezoelectric) voltage output |
| Supply Voltage | 18 to 30 V DC constant current source (2–10 mA) |
| Mounting Method | ¼-28 UNF stud mount or adhesive base |
| Connector Type | 2-pin MIL-C-5015 connector |
| Housing Material | 316L stainless steel |
| Protection Rating | IP67, industrial grade |
| Applications | Machine vibration monitoring, rotating equipment condition analysis |
| Operating Temperature | –40 °C to +120 °C |
| Dimensions | Diameter: 25.4 mm (1.00 in); Height: 30.5 mm (1.20 in) |
| Weight | ~0.11 kg (110 g) |
FAQ
FAQ
Q1: What is the function of the Bently Nevada 18622-010-01 sensor?
A1: It measures vibration acceleration in rotating machinery, converting mechanical motion into an electrical signal for monitoring and diagnostics.
Q2: What measurement range does it support?
A2: The typical measurement range is 0 to 50 g, suitable for most industrial vibration monitoring applications.
Q3: What type of output does the sensor provide?
A3: It provides a voltage output using IEPE (Integrated Electronics Piezoelectric) technology.
Q4: What is the sensitivity of the 18622-010-01?
A4: The sensor offers a nominal sensitivity of 100 mV/g, providing accurate response to vibration levels.
Q5: What are the power requirements?
A5: It operates from an 18–30 V DC constant current source, drawing 2–10 mA.
Q6: How is the sensor mounted?
A6: It can be mounted using a ¼-28 UNF stud or an adhesive base, depending on the installation environment.
Q7: What are its size and weight?
A7: The sensor measures 25.4 mm in diameter, 30.5 mm in height, and weighs approximately 0.11 kg.
Q8: What environments can it operate in?
A8: It is built from 316L stainless steel, rated IP67, and can operate from –40 °C to +120 °C in harsh industrial conditions.
