Technical Specifications
| Item | Specification |
|---|---|
| Model | 1900/25‑01‑00 |
| Type | Single‑channel locally mounted vibration monitor |
| Transducer Input | Accepts compatible accelerometers (e.g., 100 mV/g sensitivity) |
| Maximum Acceleration Input | 20 g peak |
| Signal Conditioning | Converts input to peak velocity units; full scale ~50.8 mm/s (2 in/s) zero‑to‑peak |
| High‑pass Corner Frequency | –3 dB at 8 Hz |
| Low‑pass Corner Frequency | Greater than 4 kHz |
| Buffered Transducer Output | 19.7 mV/mm/s (500 mV/in/s) output sensitivity |
| Display / LCD | Integrated LCD display, refresh rate ~0.8 s |
| Indicators | LED indicators for OK, Alert, Danger status |
| Isolation | Galvanic optical isolation ~1000 Vac or 707 Vdc |
| Mounting / Power Options | Options include 85‑264 Vac / 110‑370 Vdc or 18‑36 Vdc |
| Operating Temperature | –20 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Dimensions | Approx. 250 mm × 150 mm × 120 mm |
| Weight | Approx. 2.0 kg (4.4 lb) |
FAQ
FAQ
Q1: What is the purpose of the 1900/25‑01‑00 monitor?
A1: It is a stand‑alone vibration monitor for rotating machinery that accepts a transducer input, processes the vibration into velocity units, displays status locally, and provides alarm relay outputs.
Q2: What kind of transducer can it accept and what sensitivity is typical?
A2: It accepts compatible accelerometer inputs, typically with sensitivity of 100 mV/g, and a maximum input acceleration of 20 g peak.
Q3: What measurement range does the monitor output represent?
A3: The full‑scale output is approximately 50.8 mm/s (2 in/s) zero‑to‑peak for vibration velocity.
Q4: What are the frequency response characteristics?
A4: The high‑pass corner is –3 dB at 8 Hz; the low‑pass corner is greater than 4 kHz, allowing accurate measurement across a broad vibration spectrum.
Q5: Does the monitor provide any operator interface?
A5: Yes — it features an LCD display with ~0.8 s refresh rate and LED indicators showing OK, Alert, and Danger statuses.
Q6: What power supply options are available?
A6: The monitor can be powered from 85–264 Vac (or 110–370 Vdc) or from 18–36 Vdc, depending on configured version.
Q7: What are the temperature limits for operation and storage?
A7: Operating ambient temperature is –20 °C to +70 °C; storage temperature is –40 °C to +85 °C.
Q8: Is this monitor suitable for protective use on critical machinery?
A8: Yes — it is designed for machinery protection, providing local monitoring, alarm relay outputs, and buffered transducer output for integration or trending.
