Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 21000-16-05-15-062-03-02 |
| Probe Type | 3300 XL 8 mm |
| Probe Cable Length | 0.5 m (20 in) |
| Standoff Adapter Length | 1.5 in (38 mm) |
| Probe Penetration Length | 6.2 in (157 mm) |
| Fitting Option | One 3/4-14 NPT plug, one 3/4-14 to 1/2-14 NPT reducer, cable seal grip with grommets for cable sizes 1/8–3/16 in, 1/4–5/16 in, 5/16–3/8 in |
| Mounting Thread | 3/4-14 NPT |
| Housing Material | Aluminum body with 304 stainless steel sleeve |
| Operating Temperature | -51°C to +177°C (-60°F to +351°F) |
| Enclosure Type | CSA Type 4, API 670 compliant |
| Housing Body Diameter | 83.3 mm |
| Weight | 1.1 kg |
FAQ
FAQ
-
What is the maximum operating temperature for this probe housing?
The housing can operate up to +177°C (351°F), maintaining reliable performance in high-temperature environments. -
Which probe types are compatible with this housing?
It is compatible with Bently Nevada 3300 XL 8 mm proximity probes. -
What mounting options are available for this housing assembly?
The housing uses a 3/4-14 NPT mounting thread and includes standoff adapters for proper probe positioning. -
What material is used for the housing body and sleeve?
The housing body is made of aluminum, and the sleeve is 304 stainless steel to ensure corrosion resistance. -
Is this housing suitable for explosion-proof applications?
Yes, it is CSA Type 4 rated and designed for externally mounted probes, compliant with API 670. -
What is the penetration length of the probe in this housing?
The probe penetration length is 6.2 inches (157 mm). -
How are cables sealed within the housing?
The housing includes cable seal grips with grommets accommodating cable sizes from 1/8 to 3/8 inches. -
What is the weight and diameter of the housing body?
The housing body diameter is 83.3 mm and its weight is 1.1 kg.
