Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | 21000-28-05-20-044-04-02 |
| Housing Material | Aluminum body with 304 stainless steel sleeve |
| Operating Temperature (8mm/11mm) | -51°C to +177°C (-60°F to +351°F) |
| Operating Temperature (NSv) | -34°C to +177°C (-30°F to +351°F) |
| Storage Temperature | -51°C to +177°C (-60°F to +351°F) |
| Explosion Proof Rating | CSA certified for Class I/II/III, Div 1 and 2, Groups C-G, Type 4 |
| Compliance | RoHS Directive 2011/65/EU, API 670 compliant |
| Sleeve Length Support Requirement | >304 mm requires additional support |
| Housing Body Diameter | 83.3 mm |
| Overall Length | 161.6 mm |
| Weight | 1.1 kg (2.4 lbs) |
| Mounting Thread | 3/4-14 NPT |
| Fittings Option | One 3/4-14 NPT plug + one 3/4-14 to 1/2-14 NPT reducer |
| Probe Type | 3300 XL 8mm probe with hazardous area approval |
| Cable Length | 0.5 m (20 inches) |
| Standoff Adapter Length | 2.0 in (44 mm) |
| Probe Penetration Length | 4.4 in (112 mm) |
FAQ
FAQ
Q1: What type of probe is used in the 21000-28-05-20-044-04-02 housing?
A1: It uses a 3300 XL 8mm proximity probe with selectable hazardous area approval.
Q2: What is the maximum operating temperature of this housing assembly?
A2: It supports up to +177°C for all compatible probe types.
Q3: Is this housing suitable for explosive environments?
A3: Yes, it is CSA-certified explosion-proof for Class I, II, and III, Divisions 1 and 2.
Q4: What material is used in the housing and sleeve?
A4: The housing is made of aluminum, and the sleeve is made of 304 stainless steel.
Q5: How long can the probe sleeve be before it requires additional support?
A5: Sleeve lengths longer than 304 mm (12 inches) need extra support to prevent vibration.
Q6: What are the external dimensions of the housing body?
A6: The body diameter is 83.3 mm, and the total length is 161.6 mm.
Q7: How much does the housing weigh?
A7: Approximately 1.1 kg without fittings.
Q8: Which industry standard does the housing comply with?
A8: It complies with the API 670 standard for externally mounted proximity probe housings.
