Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Bently Nevada 21505-00-12-05-02 |
| Series | 7200 8 mm Standard Mount Armored Probe |
| Probe Type | Non-contact eddy-current proximity probe |
| Sensing Principle | Eddy current displacement measurement |
| Measurement Range | ±1.0 mm typical linear range |
| Linear Range | 2 mm (approx.) |
| Sensitivity | 7.87 V/mm (nominal) |
| System Compatibility | Compatible with 7200 Proximitor modules and extension cables |
| Target Material | AISI 4140 steel (standard) |
| Operating Temperature | −40°C to +177°C |
| Cable Type | Armored coaxial cable |
| Cable Connector | Standard industrial connector |
| Shielding | Armored cable provides EMI protection |
| Typical Applications | Shaft vibration monitoring, position measurement, thrust monitoring, differential expansion |
| Total Length | 0.5 meter |
| Weight | 0.22 kg |
FAQ
FAQ
Q1: Which machines is this probe intended for?
A1: It is used in turbines, generators, and other rotating machinery requiring precise shaft position and vibration monitoring.
Q2: Can this probe operate at high rotational speeds?
A2: Yes, its eddy-current sensing ensures accurate measurements at high shaft speeds.
Q3: How should the probe be mounted for accurate readings?
A3: Mount perpendicular to the target surface with the recommended gap to maintain linearity.
Q4: How does it resist electrical noise?
A4: The armored cable provides excellent shielding against electromagnetic interference.
Q5: Is it suitable for extreme temperature conditions?
A5: Yes, it operates reliably from −40°C to +177°C.
Q6: What maintenance is required?
A6: Inspect the probe tip, cable, and connectors periodically; recalibration is needed only if physical damage occurs.
Q7: Can multiple probes be used in one system?
A7: Yes, multiple 7200 series probes can connect to Proximitor channels for comprehensive shaft monitoring.
Q8: Are there limitations on target material?
A8: The probe is optimized for ferromagnetic materials such as AISI 4140 steel; non-ferrous materials may reduce accuracy and linearity.
