Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Bently Nevada 21505-00-28-05-02 |
| Product ID | 21505-00-28-05-02 |
| Manufacturer | Bently Nevada |
| Product Type | Proximity Probe Housing Assembly |
| Series | Bently Nevada 21505 Housing Assembly Series |
| Function | Provides mounting, protection, and adjustment access for proximity probes in machinery monitoring systems |
| Probe Type | 3300 XL 11 mm proximity probe (Option 28) |
| Probe Cable Length | 0.5 m (19.7 in) |
| Housing Material | Aluminum body with stainless steel components |
| Mounting Thread | 3/4-14 NPT |
| Environmental Protection | Industrial-duty sealed construction |
| Compatible Systems | Bently Nevada 3300 XL 11 mm Proximity Transducer System |
| Measurement Capability | Shaft vibration and shaft position monitoring |
| Installation Type | External machine housing installation |
| Operating Temperature | -34°C to +177°C (probe dependent) |
| Storage Temperature | -51°C to +177°C |
| Humidity | Suitable for industrial environments |
| Certification | Configuration dependent, suitable for API 670 applications |
| Application | Turbines, compressors, pumps, motors, generators, and other rotating machinery |
| Protection Features | Probe protection, environmental sealing, external adjustment capability |
| Dimensions (H × W × D) | Approx. 180 × 85 × 35 mm |
| Weight | Approx. 1.0 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Bently Nevada 21505-00-28-05-02 used for?
It is a proximity probe housing assembly designed to mount and protect a proximity probe used for machinery vibration and position monitoring.
Q2: Which probe is included with this configuration?
This model is configured for a Bently Nevada 3300 XL 11 mm proximity probe.
Q3: What machinery applications is it designed for?
It is commonly used on turbines, compressors, pumps, generators, motors, and other critical rotating equipment.
Q4: Why is a probe housing assembly required?
It protects the probe from environmental conditions and allows probe adjustment or replacement without disassembling the machine.
Q5: What monitoring measurements can be performed?
The assembly supports shaft vibration, shaft displacement, and shaft position monitoring applications.
Q6: What material is used for the housing?
The housing is manufactured from aluminum with corrosion-resistant stainless-steel components.
Q7: Is the housing compatible with API 670 machinery protection systems?
Yes, it can be used in applications designed to meet API 670 machinery protection requirements.
Q8: What should be verified before replacing the housing assembly?
Users should verify probe type, cable length, mounting thread, penetration depth, and overall transducer system compatibility before installation.
