Technical Specifications
| Item | Specification |
|---|---|
| Product Model | Bently Nevada 26530-12-10-03-018-159-22-04-00 |
| Type | Dual-Probe Sensor System |
| Function | Integrates proximity and velocity/vibration sensors for shaft displacement, vibration, and casing motion measurement |
| Sensing Principle | Combination of eddy current and velocity sensing |
| Measurement Range | ±2.0 mm to ±5.0 mm (depending on probe configuration) |
| Frequency Response | 0 to 15 kHz |
| Scale Factor | 0.404 V/mm (typical) |
| Linearity | ±0.5% of full scale |
| Operating Temperature | -51°C to +177°C (proximity) / -29°C to +121°C (velocity) |
| Storage Temperature | -54°C to +93°C |
| Power Supply | ±15 VDC |
| Mounting Type | Threaded mount with 1/2-inch conduit fitting |
| Protection Class | IP65 |
| Dimensions | Probe Lead Length : 1.0 meter |
| Weight | Shipping weight 3 kg |
FAQ
FAQ
Q1: What is the main application of this dual-probe sensor system?
A1: It monitors shaft radial displacement, vibration, and casing absolute motion, commonly used in large rotating machinery monitoring systems.
Q2: What components make up this system?
A2: It consists of one eddy-current proximity probe and one velocity/vibration transducer integrated within a single housing.
Q3: What are the advantages of a dual-probe design?
A3: It provides simultaneous measurements of both relative and absolute shaft motion, improving accuracy and reducing installation error.
Q4: What is the operating temperature range?
A4: The proximity probe operates from -51°C to +177°C, and the velocity sensor from -29°C to +121°C.
Q5: What types of machines is this system suitable for?
A5: Suitable for turbines, compressors, pumps, and generators requiring precise vibration and expansion monitoring.
Q6: What are the product dimensions and weight?
A6: Probe Lead Length : 1.0 meter, and shipping weight is 3 kg.
Q7: How is the unit mounted?
A7: It uses threaded mounting with a 1/2-inch conduit fitting for easy installation and cable management.
Q8: Can the probe length or options be customized?
A8: Yes, probe length, cable length, and thread type can be customized according to installation requirements.
