Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Bently Nevada 3300/25 |
| Product ID | 3300/25 |
| Manufacturer | Bently Nevada |
| Product Type | System Keyphasor® Module |
| Series | Bently Nevada 3300 Machinery Protection System |
| Function | Provides once-per-revolution reference signal for phase measurement and speed monitoring |
| Input Type | Proximity probe or magnetic pickup input |
| Output Signal | Keyphasor reference pulse (TTL-compatible system signal) |
| Channels | Typically 1–2 channels (configuration dependent) |
| Speed Range | Suitable for low to high-speed rotating machinery |
| Signal Processing | Phase reference generation and speed calculation support |
| System Interface | 3300 rack backplane communication |
| Power Supply | Powered via 3300 system rack |
| Mounting Type | Rack-mounted module |
| System Compatibility | Bently Nevada 3300 series machinery protection system |
| Diagnostics | Sensor signal health and module status monitoring |
| Configuration | System software and rack configuration dependent |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to +65°C |
| Storage Temperature | −40°C to +85°C |
| Humidity | 95% non-condensing |
| Cooling Method | Natural convection |
| Application | Turbines, compressors, pumps, generators, rotating machinery speed and phase monitoring |
| Dimensions (H × W × D) | Approx. 241 × 24 × 241 mm |
| Weight | Approx. 0.45 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Bently Nevada 3300/25 used for?
It is a Keyphasor module used to generate a once-per-revolution reference signal for phase and speed measurement in rotating machinery.
Q2: What is a Keyphasor signal?
A Keyphasor signal is a reference pulse that indicates one complete revolution of a shaft, used for phase analysis and vibration diagnostics.
Q3: What sensors are compatible with this module?
It typically works with proximity probes or magnetic pickup sensors depending on system configuration.
Q4: What is its main function in the system?
It provides timing reference signals used for phase-related vibration analysis and machine speed monitoring.
Q5: Does it operate independently?
No. It must be installed in a Bently Nevada 3300 system rack.
Q6: What equipment uses this module?
It is used on turbines, compressors, pumps, generators, and other rotating machinery requiring phase reference signals.
Q7: Can it support multiple channels?
Yes, depending on configuration it can support one or more input channels.
Q8: What should be checked before replacement?
Users should verify sensor type, rack compatibility, system configuration, and Keyphasor setup parameters before replacement.
