Technical Specifications
| Item | Specification |
|---|---|
| Model | 330101-00-14-20-02-CN |
| Type | Bently Nevada 3300 XL 14 mm Proximity Probe |
| Measurement Principle | Eddy-current non-contact displacement measurement |
| Probe Tip Diameter | 14 mm (0.55 in) |
| Thread Size | M16 × 1.5 |
| Probe Length | 100 mm (nominal) |
| Cable Length | 20 m integral cable |
| Sensitivity | 7.87 mV/µm (200 mV/mil) |
| Measurement Range | 4.0 mm (160 mils) |
| Frequency Response | DC to 10 kHz |
| Linearity | ±1% of full scale |
| Housing Material | Stainless steel |
| Tip Material | PEEK (polyether ether ketone) |
| Mounting Method | Threaded installation |
| Operating Temperature | -35°C to +177°C |
| Protection Rating | IP67 |
| Matching Components | 330130-0X-00 Extension Cable and 3300 XL Proximitor Sensor |
| Special Code “CN” | China-localized version certified for regional standards and local compliance |
| Applications | Shaft vibration, axial position, and displacement monitoring |
| Dimensions | Probe tip diameter 14 mm, body length 100 mm |
| Weight | Approximately 0.45 kg |
FAQ
FAQ
Q1: What is the function of the 330101-00-14-20-02-CN proximity probe?
It is used to measure shaft vibration, axial displacement, and position in rotating machinery such as turbines, compressors, and pumps.
Q2: What does the “CN” suffix indicate?
The “CN” code denotes that this is a China-localized version, built and certified according to local regulations while maintaining the same technical performance as the standard version.
Q3: What technology is used for measurement?
It uses eddy-current sensing technology, offering precise, non-contact measurement of conductive target surfaces.
Q4: What is the cable length for this probe model?
This model includes a 20-meter integral cable, suitable for installations requiring long-distance signal transmission.
Q5: Which Proximitor sensor is compatible with this probe?
It is designed to operate with the Bently Nevada 3300 XL Proximitor Sensor for accurate calibration and system compatibility.
Q6: What environmental protection does this probe provide?
With an IP67 rating and stainless-steel housing, it offers excellent resistance to oil, dust, and moisture.
Q7: What is the operating temperature range?
The probe functions effectively from -35°C to +177°C, ensuring reliable performance in demanding industrial environments.
Q8: What are the typical applications for this probe?
It is commonly used in power generation, petrochemical, and heavy industrial machinery for continuous vibration and displacement monitoring.
